HMC2070A-M

  • Support for up to 3 I/O Expansion Modules
  • IEC 61131-3 Programming Logic
  • Class I, Division 2 Rated
  • Send files via FTP
  • Web Server

Compatible I/O

7.0" Standard HMI + PLC

HMC2070A-M

$545.00

Buy Now

Expandable Class I Division 2, HMI+ PLC combines the ease of a graphic HMI with PLC functionality in one unit and one software. Pair this with up to three HMC3 I/O modules, listed below, to make this HMI + PLC customized and cost effective for your application. Paired with free configuration software, the HMC2070A-M is one of our most affordable and functional HMC + PLC models.

Specifications

System

Memory (RAM)

16 MB

Memory (Flash)

16 MB

RTC

Built-in

Application Memory

8 MB

Programming Software

MAPware V2.36 or later versions

PLC Ladder Memory

2 MB

PLC Ladder Logic

Yes

I/O Ports

Serial Ports

2

Ethernet/LAN

10/100 Base-T x 1

CANbus

N/A

Audio Output

N/A

SD Card Slot

SD/SDHC (32GB capacity)

USB Host Ports

USB 2.0 x 1

USB Client Ports

USB 2.0 x 1

Wi-Fi

N/A

COM Port

COM1: RS-232/RS-485 2W/4W, COM2: RS-232/RS-485 2W/4W

RS-485 Dual Isolation

N/A

Local bus

N/A

HDMI Port

N/A

Video Input

N/A

Siemens MPI

N/A

I/O

Expandable

I/O Slots

3

Max I/O Points (Digital)

96

Max Digital In

48

Max Digital Out

48

Max I/O Points (Analog)

15

Max Analog In

12

Max Analog Out

3

Display

Display Size

7" TFT

Resolution

800 x 480

Luminance (cd/m^2)

350

Contrast Ratio

500:1

Backlight Type

LED

Backlight Lifetime (hrs)

>30000 hrs.

Colors

32 K

LCD Viewing Angle (T/B/L/R)

70/70/80/80

Touch Screen

Type

TFT Resistive

Accuracy

N/A

Touch Panel Hardness Scale

N/A

Electrical

Power Isolation

Built-in

Power Dissipation

N/A

Current for Internal Bus

N/A

Current Consumption

N/A

Voltage Resistance

N/A

Isolation Resistance

N/A

Mechanical

Vibration Endurance

5 to 150Hz (X, Y, Z direction 3G peak)

Enclosure Material

Black Plastic

PCB Coating

N/A

Dimensions WxHxD

7.32 x 5.43 x 1.22 [186mm x 138mm x 31mm]

Panel Cutout (inches) [mm]

6.88 x 5.00 [175 x 127]

Weight

Approx. 0.88 lbs. [0.4 Kg]

Mounting

Panel mount

Shock (Operation)

25 g acceleration for 11 ms

Environmental

Storage Temperature

-4° ~ 185°F (-20° ~ 85°C)

Operating Temperature

32° ~ 122°F (0° ~ 50°C)

Relative Humidity

10% ~ 95% (non-condensing)

Certification

UL Type Rating

UL Class 1 Div 2

NEMA Rating

N/A

IP Rating

IP66 Compliant Front Panel

CE

Yes

UL

cULus Listed

Class 1 Div 2

Yes

ATEX

N/A

RoHS

Yes

Available Software

What's Included

When you order the HMC2070A-M the following items are included in the box:

  • HMC2070A-M
  • Warranty Statement
  • Installation Instruction
  • Product Flyer
  • Power Connector
  • Mounting Kit
