Communication Cables
At Maple Systems we offer hundreds of custom communication cable drawings for the industry’s most popular PLC manufacturers. Whether you want to build your own cable or have us build it for you, we can provide you with exactly what you need.
Please double-check to make sure you have identified the proper cable for your unit as all custom cables are made to order and are non-refundable. If you are unsure which cable you need or wish to place an order, contact Sales for assistance at sales@maplesystems.com or call (425) 745 3229.
The information in these cable tables is subject to change without notice as we continue to update and expand our custom cable offering.
HMI / cMT Cable Configurator
Use the tool to search in two ways:
-
Search by Model:
- Select Product Model
- Select Controller Model
- Select Cable Length
- Click Search
-
Search by Part Number:
- Enter the part number (with or without hyphens)
- Click Search
Note 1: The SLC 5/01 and SLC 5/02 require the use of an Allen-Bradley Communications Interface Module.
Note 2: The Siemens S7-300 requires the use of an HMI adapter (Maple P/N 7431-0107) to allow communications to a Graphic HMI. Please contact Maple Systems for pricing information and lead time.
Alphanumeric OIT & ASCII Terminal Cable Configurator
Use the tool to search in two ways:
-
Search by Model:
- Select Product Model
- Select Controller Model
- Select Cable Length
- Click Search
-
Search by Part Number:
- Enter the part number (with or without hyphens)
- Click Search
