HMI + Remote I/O + CODESYS

Select Maple HMIs have a sleek hardware platform that runs both an HMI application created with EBpro and PLC logic programmed with CODESYS; each on its own dedicated processor. Unlike the typical multicore set up, where the operating system scheduler is responsible for allocating tasks to each processor, these HMIs have a hard separation between cores. One core is dedicated to the HMI application, the other to executing PLC logic of the CODESYS project. This ensures taxing graphics processing operations will not interfere with deterministic real time control tasks executing on the other processor.

After selecting your HMI, choose from a suite of easy to use powerful I/O modules to connect to your field equipment. We offer a complete set of I/O modules which can be combined with any of three communication couplers to create a remote I/O block.

CODESYS Overview
Hardware Platform
Couplers & I/O
Documentation & Resources
Configuration Software
Try Before You Buy

Getting Started

Combine the power of CODESYS with one of our CODESYS capable HMIs and Modular IO to create an innovative control solution that can tackle the most demanding applications. This unique architecture saves time, hardware cost, communication cabling, and valuable control cabinet real estate, without compromising on the CPU resources real time applications require. See our project example below and get started building your solution today!

1

Select Controller or your HMI

Choose either a stand-alone Controller or one of our innovative multi-core CPU HMIs with CODESYS. 2 cores are dedicated to running the CODESYS runtime while the other 2 can run a full EBPro HMI application. Add up to 16 IO modules.  Contact sales if you are looking to add a CODESYS license to an existing HMI.  Refer to specific datasheets for supported models.

2

Select Your Communication Coupler

iR Communication Couplers have three interface protocols to choose from: Modbus TCP, CANopen and EtherCAT all of which seamlessly integrate into your EBPro and CODESYS Projects.



3

Select Your I/O Modules

Easy to use reliable IO modules complete the connection to your field equipment. Attach up to 16 IO modules to a coupler. Select from analog, digital, temperature or motion control i/o modules.



4

Get Your CODESYS Activation Card

We’ve already activated the CODESYS license on our HMI-enabled models.  Selecting a CODESYS enabled cMT HMI with activated CODESYS license creates a powerful HMI + I/O controller by allowing the HMI to run IEC 61131-3 programming logic, and handle all the data processing, and reading/writing to applicable I/O modules.  Contact sales for stand-alone CODESYS licenses to pair with your existing cMT HMI (select models only) and How to Activate CODESYS on cMT Models.

5

Download EBPro HMI Configuration Software

Free, powerful HMI configuration software for our HMIs provides the flexibility to create and deploy custom control applications suited to your unique industrial process. Read more about EBPro HMI Configuration Software.






6

Download CODESYS Development Software

A complete PLC software package backed by a large userbase and development team, CODESYS fully implements the IEC 61131-3 specification.







7

Download our CODESYS Quick Start Guide

Follow this guide for step-by-step instruction on how to set up one of our CODESYS-supported HMIs and our Remote I/O.






8

Download Weintek CODESYS Package

This package should be installed as an add-in after you install the CODESYS development software.






9

EasyRemote IO Software

Easy Remote IO allows users to scan their network for iR couplers and modules and establish communication with them so they can be used in a CODESYS project. Used to generate tag files that can be imported into CODESYS and EBPro for easy addressing.



Visit our CODESYS Software page to learn more.

Example Setup:

As example consider creating a control system for a high temperature gas kiln. The system requirements might include:

  1. Large touchscreen display, remotely mounted.
  2. Several digital inputs to monitor safety interlocks and manual switches.
  3. Digital outputs to control warning lights valves and an ignitor.
  4. Analog inputs used to monitor gas flow.
  5. Temperature inputs to monitor several thermocouples.

This system could be implemented with the following equipment:

  1. cMT3092Xv2-CODESYS – a 9.7″ touchscreen HMI with a CODESYS license that will run the HMI project and the CODESYS control logic.
  2. iR-ETN coupler to create a remote IO block connected to CODESYS using Modbus TCP.
  3. The following IO modules to connect to field devices:
    • iR-DM16-P – 8 digital inputs and 8 sourcing digital outputs
    • iR-AM06-VI – 4 analog input channels and 2 analog outputs
    • iR-AI04-TR – 4 RTD / Thermocouple inputs

Select your Controller or Supported HMI

Product Categories
Display Size
Price
CANBus
Class1 Div2
CODESYS
Color
Display Out
Display Resolution
Enclosure Material
Ethernet Ports
Operating Temperature
Remote Access/IIoT Features
SD Card Slots
Serial Ports
Series
Touch Screen Type
UL Certified
USB Ports
Wi-Fi

Add Your I/O

Communication Couplers

I/O Modules

(up to 16 modules per Controller or Communication Coupler)

Documentation

Here’s the list of documents that support our CODESYS / cMT products:

Manuals & Guides
CODESYS / cMT Quick Start Guide
iR-ETN User Manual

iR-ETN40R User Manual
iR-COP User Manual
iR-ECAT User Manual
iR-Analog Module User Manual

Sample Projects
Communicating to I/O Module Sample Project
iR-COP Sample Project
iR-ECAT Sample Project
iR-ETN Sample Project

iR-ETN40R Sample Project

Support Documents
CODESYS Activation instructions

Other Resources

Weintek CODESYS package – This package should be installed as an add-in after you install the CODESYS development software.
