cMT2128X

12.1" Advanced HMI with Dual-Ethernet

cMT2128X

$1,399.00

Buy Now

12″ touch panel powered by a Quad-Core RISC processor, 4 GB flash memory, and 1 GB RAM. Experience seamless multitasking with the cMT2128X, as it effortlessly handles multiple tasks. Unlock the power of remote access, IIoT functionality, and an advanced feature set for your application. Enhance its capabilities by pairing with a remote IO and CODESYS license for soft PLC functionality. With our free HMI software supporting Modbus and over 300 PLCs and controllers, integration with your Allen-Bradley, Siemens, Omron, Emerson, and other PLCs is quick and hassle-free.

Specifications

System

Memory (RAM)

1 GB

Memory (Flash)

4 GB

RTC

Built-in

Programming Software

EasyBuilder Pro V6.06.02 or later versions

I/O Ports

Serial Ports

2

Ethernet/LAN

1 x 10/100 Base-T RJ-45, 1 x GbE RJ-45

CANbus

N/A

Audio Output

N/A

SD Card Slot

1 x Micro SD

USB Host Ports

USB 2.0 x 1

USB Client Ports

N/A

Wi-Fi

N/A

RS-485 Dual Isolation

Yes

HDMI Port

N/A

Video Input

N/A

Display

Resolution

1024 X 768

Luminance (cd/m^2)

500

Contrast Ratio

1000:1

Backlight Type

LED

Backlight Lifetime (hrs)

30,000+

Colors

16.7 M

View Angle (H° V°)

178/178

Display Type

12.1” WVA LCD

Viewing Angle (H°/V°)

178/178

Size (W x H)

9.70 x 7.30 inches [246.5 x 185.3. mm]

Touch Screen

Type

4-wire resistive touch

Accuracy

Length (X) ±2%, width (Y) ±2%

Electrical

Input Power

28.8 W

Power Isolation

Built-in

Isolation Resistance

Exceed 50 MO - @ 500 VDC

Input Voltage

24 ± 20% VDC

Input Current

1.2 A @ 24 VDC

Mechanical

Vibration Endurance

10 to 25Hz (X, Y, Z direction 2G 30 minutes)

Enclosure Material

Black Plastic

PCB Coating

Yes

Dimensions WxHxD

12.49 x 9.57 x 1.62 inches [317 x 243 x 41 mm]

Panel Cutout (inches) [mm]

12.01 x 9.09 [305 x 231]

Weight

Approx. 3.75 lbs. [1.7 kg]

Mounting

Panel mount, VESA 75 x 75 mm

Environmental

Storage Temperature

-4° ~ 140°F (-20° ~ 60°C)

Operating Temperature

32° ~ 131°F (0° ~ 55°C)

Relative Humidity

10% ~ 90% (non-condensing)

Certification

UL Type Rating

UL Type 4X (indoor use only)

NEMA Rating

NEMA4

IP Rating

IP66 Compliant Front Panel

CE

Yes

UL

cULus Listed

RoHS

Yes

What's Included

When you order the cMT2128X the following items are included in the box:

  • 1 x cMT2128X
  • 1 x Warranty Statement
  • 1 x Installation Instruction
  • 1 x Product Brochure
  • 1 x Power Connector
  • 8 x Panel Mounting Clips
  • 1 x Spare Fuse
