cMT2058XH
- TFT LCD with 800 x 480 Pixel Resolution
- Quad-Core 64-bit RISC, 1.5 GHz
- 2 Ethernet, 1 USB, 2 Serial Ports
- MQTT, Sparkplug B, WebView, VNC
- Add an EasyAccess2.0 license for remote access
- Pair with our remote IO for CODESYS functionality
- UNBRANDED
4.3" Dual-Ethernet Advanced HMI
cMT2058XH
The cMT2058XH is a powerful HMI with dual Ethernet, remote access, and IIoT functionality. Pair this operator interface with our remote IO and CODESYS license for soft PLC functionality. With a sleek blank overlay, integrating this HMI into your machine is seamless. Try pairing with one of our Micro or Modular PLCs for one-stop shopping! Connect your Maple Systems HMI with a Maple Systems PLC.
Try Before You Buy: Follow along to learn how EBPro, our 100% free HMI configuration software, allows you to develop and simulate your HMI program entirely free of charge.
- Compare cMT2058XH and other models.
- Volume Discounts available. Contact Sales for more details.
- Customize your product with your company logo. Minimum quantities apply.
- Learn More about how our products interface with over 300+ PLCs and Controllers.
- US Based Technical Support
Specifications
System
| Memory (RAM) | 1 GB |
| Memory (Flash) | 4 GB |
| RTC | Built-in |
| Programming Software | EBPro (Latest Version) |
I/O Ports
| Serial Ports | 1 |
| Ethernet/LAN | 1 x 10/100 Base-T RJ-45, 1 x GbE RJ-45 |
| CANbus | N/A |
| Audio Output | N/A |
| SD Card Slot | N/A |
| USB Host Ports | USB 2.0 x 1 |
| USB Client Ports | N/A |
| Wi-Fi | N/A |
| COM Port | 1 x DE9P COM1: RS-232/RS-485 2 or 4 wire, COM 3: RS-485 2 wires |
| HDMI Port | N/A |
| Video Input | N/A |
Display
| Display Size | 4.3" WVA LCD |
| Resolution | 800 x 480 |
| Luminance (cd/m^2) | 530 |
| Contrast Ratio | 800:1 |
| Backlight Type | LED |
| Backlight Lifetime (hrs) | 30,000+ |
| Colors | 16.7 M |
| Display Type | 4.3" WVA |
| Viewing Angle (H°/V°) | 160/160 |
| Size (W x H) | 3.74 x 2.13 inches [95 x 54 mm] |
Touch Screen
| Type | 4-wire resistive touch |
| Accuracy | Length (x)±2%, Width(y)±2% |
Electrical
| Input Power | 12.2 W |
| Power Isolation | Built-in |
| Isolation Resistance | Exceed 50 MO - @ 500 VDC |
| Input Voltage | 24 ± 20% VDC |
| Input Current | 510 mA @ 24 VDC |
Mechanical
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| Enclosure Material | Plastic, charcoal grey |
| PCB Coating | Yes |
| Dimensions WxHxD | 5.04 x 4.02 x 1.26 inches [128 x 102 x 32 mm] |
| Panel Cutout (inches) [mm] | 4.69 x 3.66 [119 x 93] |
| Weight | Approx. 0.6 lbs. [0.27 kg] |
| Mounting | Panel mount |
Environmental
| Altitude (Air Pressure) | Below 3000 meters (70.1kPa) |
| Storage Temperature | -4° ~ 140°F (-20° ~ 60°C) |
| Operating Temperature | 32° ~ 122°F (0° ~ 50°C) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
Certification
| CE UKCA | Yes |
| UL Type Rating | UL Type 4X (indoor use only) |
| NEMA Rating | NEMA4 |
| IP Rating | IP66 Compliant Front Panel |
| CE | Yes |
| UL | cULus Listed |
| Class 1 Div 2 | N/A |
| ATEX | N/A |
| RoHS | Yes |
Accessories
Customers who bought this product also bought:
Available Software
FREE User Friendly HMI Software
Download our free, full-featured HMI configuration software to create custom control applications for your industrial process. EBPro supports over 300 PLC & controller protocols, ensuring seamless integration with new or existing systems. No license or key required.
Documentation & Resources
Documents
Manuals
- EBPro Programming Manual
- EBPro Quick Start Guide
- cMT Quick Start Guide
- CMT2058XH Installation Guide
- cMT/HMI MQTT User Manual
- CODESYS / cMT Quick Start Guide
- CODESYS Activation instructions
- EasyWeb 2.0-Operations-Manual
Certifications
- UL Certification
- CE Certification
- RoHS Certification
- REACH Certification
- EU Declaration of Conformity
- Trade Agreement Act
- Russian Iron and Steel Declaration
Need Additional Support?
Maple Systems
808 134th St. SW, Suite 120
Everett, WA 98204
Phone: 425.745.3229
Fax: 425.745.3429
Email: sales@maplesystems.com
Business Hours:
Monday – Friday 6:00am – 4:30pm (PST)
What's Included
When you order the cMT2058XH the following items are included in the box:
- cMT2058XH Touchscreen HMI
- Warranty Statement
- Installation Instruction
- Power Connector
- Mounting Clips
