5 Port Unmanaged Industrial Network Switch
$100.00
For use with all product
MS1-U05L is an unmanaged industrial switch used to expand ethernet networks in factory floors and for high demanding environments with simple requirements and limited space.
This switch offers auto-negotiation on all its ports to send data across devices efficiently in industrial ethernet applications, and in-built traffic optimization with Flow and Storm Control Features to offer reliable performance and prevent packet loss transporting VLAN packets without modifying them.
This networking device is built with industrial grade components to protect it from hazards like vibration, shock, free fall, interference, and extreme temperatures that make it resistant to harsh industrial environments.
- US-based technical support.
Share the product:
MS1-U05L Highlights
- 5 x 10/100 RJ45 ports
- Current Overload & Power Input Polarity Protection
- Auto-Negotiation, Flow Control, Storm Control, VLAN passthru
- Operating temperature -40℃~75℃ (-40°F~167°F)
- Aluminum Housing, Din-Rail / Wall Mount
- IP30, UL, CE, FCC, RoHS, EMI, EMS, Shock, Vibration
Port Specifications
| RJ45 Copper Ports | Five (5) |
| RJ45 Speed | 10/100BASE-T |
| Auto Negotiation & MDI/MDI-X | Supported |
| RJ Nominal Max. Distance | 328 feet (100 meters) |
Performance
| Packet Buffer | 448Kbits |
| Jumbo Frame Size | 1552 Bytes |
| MAC Table Size | 1K entries |
| L2 Forwarding Rate | 0.7Mpps |
| Switch Fabric | 1.0 Gbps |
| Throughput | 14,880 pps to 10 Mbps Ethernet ports 148,800 pps to 100 Mbps Fast Ethernet ports |
Traffic Control
| Flow Control | Yes |
| Storm Control | Yes |
| VLAN Passthru | Supports up to 4094 VLAN IDs |
| LLDP Filter | Yes |
| Port Priority | N/A |
| QoS Queue | N/A |
| Industrial QoS | N/A |
| 802.1p QoS/CoS | N/A |
IEEE Standards
| Compliance | 802.3, 802.3u, 802.3x |
Power Details
| Input Connector | Terminal Block |
| Max Input Current | 0.125A @ 24VDC |
| Max Power Consumption | 3W |
| Current Overload Protection | Yes |
| Redundant Power System | N/A |
| Input Voltage | 12-48 VDC |
| Reverse Polarity Protection | Yes |
| Power Input Polarity Protection | Yes |
Mechanical
| LED Panel | 100, LNK/ACT |
| Dip Switches | N/A |
| Alarm Relay | N/A |
| Enclosure Material | Black Powder-Coated Aluminum |
| Dimensions WxHxD | 23.6 x 111.5 x 73.8 mm (0.93 x 4.39 x 2.90”) |
| Weight | 180g (0.40 lb) |
| Mounting | 35 mm DIN Rail, Wall Mount |
Environmental
| Operating Temperature | -40°F~167°F (-40°C~75°C) |
| Storage Temperature | -40°F~185°F (-40°C~85°C) |
| Operating/Storage Relative Humidity | 5 to 95% RH (non-condensing) |
Certifications/Standards
| UL | cULus Listed |
| RoHS | Compliant |
| FCC | Class B Compliant |
| Ingress Protection | IP30 |
| Shock Test | IEC 60068-2-27 |
| Freefall Test | IEC 60068-2-31 |
| Vibration | IEC 60068-2-6 |
| EMI / CE | FCC Part 15 Class B, EN 55011, EN 55032 Class B, EN 61000-6-4 |
| EMS / CE | EN 55024, EN 61000-6-2 IEC 61000-4-2 (ESD): Level 3, IEC 61000-4-3 (RS): Level 3, IEC 61000-4-4 (Burst): Level 3, IEC 61000-4-5 (Surge): Level 3, EN 61000-4-6 (CS): Level 3, IEC 61000-4-8 (PFMF) |
| CE UKCA | Yes |
| CE | Yes |
Unmanaged Switch Unboxing
We'll unbox our Unmanaged Industrial Network Switch, show all unmanaged options, features, and how to connect them to your network.
When you order the MS1-U05L the following items are included in the box:
1 x MS1-U05L
1 x Power Connector
2 x Wall Mount Screws
1 x Quick Start Guide
