HMI5070B

    • 800 x 480 Resolution
    • 600MHz RISC CPU
    • Non-UL Certified
    • 1 Year Warranty
    • Support for over 300 protocols

</ul >

7.0" Low-Cost HMI

HMI5070B

This is a legacy product and is no longer available for purchase. Please call (425)-745-3229 or email: sales@maplesystems.com for a recommended upgrade path.

HMI5070Bv3 replaces the HMI5070B

As part of our Standard Series, this model provides a high-quality unit for applications requiring straight-forward HMI functionality at a great price. Paired with our free software, the Standard Series is an exceptional value. See our Advanced and High Performance HMI Series if your project requires UL or additional features.

Specifications

System

Memory (RAM)

128 MB

Memory (Flash)

128 MB

RTC

Built-in

Programming Software

EasyBuilder Pro

I/O Ports

Serial Ports

1

Ethernet/LAN

10/100 Base-T x 1

CANbus

N/A

Audio Output

N/A

SD Card Slot

N/A

USB Host Ports

USB 2.0 x 1

USB Client Ports

N/A

Wi-Fi

N/A

COM Port

COM1: RS-232, COM2: RS-485 2W/4W

RS-485 Dual Isolation

N/A

Local bus

N/A

HDMI Port

N/A

Video Input

N/A

Display

Resolution

800 x 480

Luminance (cd/m^2)

400

350

300

Contrast Ratio

500:1

Backlight Type

LED

Backlight Lifetime (hrs)

30,000+

Colors

16.7 M

Display Type

7” TFT

Viewing Angle (H°/V°)

140/120

Size (W x H)

5.98 x 3.58 inches [152 x 91 mm]

Touch Screen

Type

4-wire resistive touch

Accuracy

N/A

Touch Panel Hardness Scale

N/A

Electrical

Input Power

12 W

Power Isolation

Built-in

Power Dissipation

N/A

Current for Internal Bus

N/A

Current Consumption

N/A

Isolation Resistance

Exceed 50 MO - @ 500 VDC

Input Voltage

10.5 ~ 28 VDC

Input Current

1 A @ 12 VDC ; 500 mA @ 24 VDC

Mechanical

Vibration Endurance

10 to 25Hz (X, Y, Z direction 2G 30 minutes)

Enclosure Material

Plastic, charcoal grey

PCB Coating

Yes

Dimensions WxHxD

7.89 x 5.77 x 1.34 inches [200.4 x 146.5 x 34 mm]

Panel Cutout (inches) [mm]

7.56 x 5.43 [192 x 138]

Weight

Approx. 1.15 lbs. [0.52 kg]

Mounting

Panel mount

Environmental

Storage Temperature

-4° ~ 140°F (-20° ~ 60°C)

Operating Temperature

32° ~ 122°F (0° ~ 50°C)

Relative Humidity

10% ~ 90% (non-condensing)

Certification

UL Type Rating

N/A

NEMA Rating

NEMA4

IP Rating

IP65 compliant front panel

CE

Yes

UL

N/A

Class 1 Div 2

N/A

ATEX

N/A

RoHS

Yes

Available Software

Documentation & Resources

Need Additional Support?

Maple Systems
808 134th St. SW, Suite 120
Everett, WA 98204

Phone: 425.745.3229
Fax: 425.745.3429
Email: sales@maplesystems.com

Business Hours:
Monday – Friday 6:00am – 4:30pm (PST)

What's Included

When you order the HMI5070B the following items are included in the box:

  • 1 x HMI5070B
  • 1 x Warranty Statement
  • 1 x Installation Instruction
  • 1 x Product Flyer
  • 1 x Power Connector
  • 4 x Panel Mounting Clips
