7.0" C1D2 Rated, Rugged Extended-Temperature High Performance HMI

Name: 7.0 C1D2 Rated Rugged Extended-Temperature High Performance HMI cMT3072XHTv2
SKU: cMT3072XHTv2
Availability: InStock

$869.00

Our Rugged Class I Division 2 rated cMT3072XHTv2 is an innovative, high-performance operator interface ideal for applications requiring an extended temperature range -4° ~ 131°F, an enhanced feature set, aluminum enclosure which is significantly more durable with better heat dissipation and EMI immunity, remote access, and/or IIoT functionality. A quad-core CPU which allows 2 cores to run a CODESYS application for soft PLC functionality, and the other 2 cores to run your HMI application.

Try Before You Buy: Follow along to learn how EBPro, our 100% free HMI configuration software, allows you to develop and simulate your HMI program entirely free of charge.

Customize product with your company logo. Minimum quantities apply.
Connect to +400 PLCs and Controllers.
US-based technical support.

Maple Systems cMT3072XHT - 7" C1D2 Rated HMI- Front View

Maple Systems 7" High Brightness cMT3072XHT HMI - side View

1024 x 600 High Resolution Display
CANbus, 2 Ethernet, 1 USB, 2 Serial Ports
Quad-Core 64-bit RISC Cortex-A35, 1.5 GHz
Aluminum Enclosure, -4° ~ 131°F Operating Temperature, C1D2
MQTT, OPC UA, SQL Database Integration
Add CODESYS and our I/O iR Modules for PLC control

View Datasheet Download Software

Add to Cart

This product:

Add to Cart

Total price: N/A

Datasheet 2D CAD File 3D CAD File

System

CPU	Quad-Core RISC
Memory (RAM)	1 GB
Memory (Flash)	4 GB
RTC	Built-in
Programming Software	EBPro (Latest Version)

I/O Ports

Ethernet/LAN	10/100 Base-T x 2
CANbus	Yes
Audio Output	N/A
SD Card Slot	N/A
USB Host Ports	USB 2.0 x 1
USB Client Ports	N/A
Wi-Fi	N/A
COM Port	CANbus 1 x DE9S COM2: RS-485 2 or 4 wire, COM3: RS-485 2 wires 1 x DE9P COM1: RS-232, COM3: RS-232
RS-485 Dual Isolation	N/A
Local bus	N/A
HDMI Port	N/A
Video Input	N/A
Serial Ports	2

Display

Display Size	7" WVA LCD
Resolution	1024 x 600
Luminance (cd/m^2)	550
Contrast Ratio	800:1
Backlight Type	LED
Backlight Lifetime (hrs)	30,000+
Colors	16.7 M
Display Type	7" WVA
Viewing Angle (H°/V°)	170/170
Size (W x H)	6.02 x 3.39 inches [153 x 86 mm]

Touch Screen

Type	4-wire resistive touch
Accuracy	Length (X) ±2%, width (Y) ±2%

Electrical

Input Power	19.7 W
Power Isolation	Built-in
Power Dissipation	N/A
Current for Internal Bus	N/A
Current Consumption	N/A
Isolation Resistance	Exceed 50 MΩ – @ 500 VDC
Input Voltage	24 ± 20% VDC
Input Current	820 mA @ 24 VDC

Mechanical

Vibration Endurance	10 to 25 Hz (X, Y, Z direction, 2G, 30 minutes)
Enclosure Material	Aluminum, charcoal grey
PCB Coating	Yes
Dimensions WxHxD	7.89 x 5.77 x 1.42 inches [200.4 x 146.5 x 36 mm]
Panel Cutout (inches) [mm]	7.56 x 5.43 [192 x 138]
Weight	Approx. 1.76 lbs. [0.8 kg]
Mounting	Panel mount

Environmental

Operating Temperature	-4° ~ 131°F (-20° ~ 55°C)
Storage Temperature	-4° ~ 140°F (-20° ~ 60°C)
Relative Humidity	10% ~ 90% (non-condensing)

Certification

UL Type Rating	UL Class 1 Div 2 UL Type 4X (indoor use only)
NEMA Rating	NEMA4
IP Rating	IP66 Compliant Front Panel
CE	Yes
UL	cULus Listed
Class 1 Div 2	Yes
ATEX	N/A
RoHS	Yes

Connect a Maple Systems HMI to a Maple Systems PLC

Whether you are new to Maple Systems or know our HMIs well, pairing one of our powerful HMIs with a low-cost PLC is easy.

View Integration Guide

Unboxing a cMT3072XHT

We'll unbox, show the I/O ports and accessories, and explore demo project and system settings,

Watch on YouTube
