10.1" Secondary Display for cMT Devices
$929.00
- Secondary Display for cMT Devices – Display Only
Our 10.1″ capacitive touch cMT3108XPiV display only unit has a fanless cooling system, NEMA4/IP66/ATEX rating, and a PCB coating, making this ideal for harsh environments.
- No project installation necessary
- Easy to connect
- Can be paired with any cMT Series HMI, including cMT-SVRX and cMT-FHDX headless models
- Up to 10 display only units can access the same project at once, further reducing programming and installation time
- Compatible with EA 2.0 and cMT Viewer, enabling access from anywhere with an internet connection
- US-based technical support.
Share the product:
- Secondary Display for cMT devices– Display Only
- Built-in cMT Viewer
- Capacitive Touchscreen Technology
- Pair with our cMT Series HMIs or our Headless HMIs
- UL Listed, NEMA4 Rated, ATEX Rated
- IP66 Rated for Washdown Environments
- 1280 x 800 Pixel Resolution
System
| CPU | Quad-Core RISC |
| Memory (RAM) | 1 GB |
| Memory (Flash) | 4 GB |
| RTC | Built-in |
I/O Ports
| Ethernet/LAN | LAN 1: 10/100/1000 Base-T x 1; LAN 2: 10/100 Base-T x 1 |
| CANbus | N/A |
| Audio Output | Built-in Mono Speaker |
| USB Host Ports | USB 2.0 x 1 |
| USB Client Ports | N/A |
| Wi-Fi | MO2 Wifi – Expansion Module (Optional) |
Display
| Display Size | 10.1" WVA LCD |
| Resolution | 1280 x 800 |
| Luminance (cd/m^2) | 425 |
| Contrast Ratio | 800:1 |
| Backlight Type | LED |
| Backlight Lifetime (hrs) | 50,000+ |
| Colors | 16.7 M |
| Display Type | 10.1” WVA LCD |
| Viewing Angle (H°/V°) | 178/178 |
| Size (W x H) | 8.58 x 5.38 inches [218 x 137 mm] |
Touch Screen
| Type | Tempered Glass, Capacitive Touch |
| Touch Panel Hardness Scale | 7H |
Electrical
| Input Power | 16.8 W |
| Power Isolation | Built-in |
| Isolation Resistance | Exceed 50 MΩ – @ 500 VDC |
| Input Voltage | 24 ± 20% VDC |
| Input Current | 700 mA @ 24 VDC |
Mechanical
| Vibration Endurance | 10 to 25 Hz (X, Y, Z direction, 2G, 30 minutes) |
| Enclosure Material | Plastic, charcoal grey |
| PCB Coating | Yes |
| Dimensions WxHxD | 10.47 x 7.72 x 1.68 inches [266 x 196 x 43 mm] |
| Panel Cutout (inches) [mm] | 10.04 x 7.28 [255 x 185] |
| Weight | Approx. 2.43 lbs. [1.1 Kg] |
| Mounting | Panel mount, VESA 75 x 75 mm |
Environmental
| Operating Temperature | 32° ~ 131°F (0° ~ 55°C) |
| Storage Temperature | -4° ~ 140°F (-20° ~ 60°C) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
Certification
| CE UKCA | Yes |
| UL Type Rating | cULus |
| NEMA Rating | NEMA4 |
| IP Rating | IP66 Compliant Front Panel |
| CE | Yes |
| UL | cULus Listed |
| ATEX | ATEX Zone 2/22 Category 3 G/D |
| RoHS | Yes |
Unboxing our cMT3108XPiV
We'll review what comes in the box, the I/O ports, pair it with a cMT HMI device, and demo how they can be used together
Documents
Manuals
Certifications
- CE UK Declaration of Conformity – cMT3108XH, cMT3108XP, cMT3108XPIV
- UL Certification Declaration – cMT Series
- Ex/ATEX Declaration of Conformity – cMT3102X, cMT3108XH, cMT3108XP
- RoHS Declaration of Conformity (all series)
- REACH EU Declaration of Conformity
- Russian Iron and Steel Declaration
- Trade Agreement Act Declaration of Conformity
- EU Declaration of Conformity (Battery Regulations)
- Country of Origin Certification
CAD Files
When you order the cMT3108XPiV the following items are included in the box:
- cMT3108XiV Display
- Warranty Statement
- 1 x Power Connector
- 7 x Mounting Clips
- 1 x USB Stick Clamp & Tying Strap
