Compare AVEVA™ Edge Products

Product comparison — attributes in rows, products in columns.

Filters
EDGEDR-64-N-231

AVEVA™ Edge 2023 R2 All Platform – Development + Runtime license, 64,000 tags, 1 Thin Client

EDGEDR-64-N-231

$10425
View Product
EDGED-11-N-231

AVEVA™ Edge Development License – All Platforms, Unlimited Tags, 1 Thin Client

EDGED-11-N-231

$5510
View Product
EDGED-32-N-231

AVEVA™ Edge 2023 R2 Development License – All Platforms, 32,000 tags, 1 Thin Client

EDGED-32-N-231

$3310
View Product
EDGEDR-64-N-231 EDGED-11-N-231 EDGED-32-N-231
License Type Development & Runtime – SCADA (Full Version) Development Only – All Platforms Development Only – All Platforms
Number of Tags 64,000 each Unlimited 32,000
Number of Supported Thin Clients Runtime – Unlimited

Number of Supported Thin Clients: Runtime – Unlimited

Limited by license and external and physical constraints (hardware and operating system).

 		N/A N/A
License Server Supported N/A N/A
USB Hardkey Supported N/A N/A
License Delivery Softkey (Hardkey optional) Softkey (Hardkey optional) Softkey (Hardkey optional)
Included Thin Clients (Development) 1 1 1
EDGEDR-64-N-231 EDGED-11-N-231 EDGED-32-N-231
Windows Server 2022 Supported N/A N/A
Windows Server 2019 Supported N/A N/A
Windows Server 2016 Supported N/A N/A
Windows 11 Supported N/A N/A
Windows 10 Supported N/A N/A
Windows 11 IoT Enterprise Supported N/A N/A
Windows 10 IoT Enterprise (LTSC/LTSB) Supported N/A N/A
Linux (x86/arm) Not Supported N/A N/A
EDGEDR-64-N-231 EDGED-11-N-231 EDGED-32-N-231
Minimum Free Storage Memory Needed 12GB N/A N/A
Minimum Free RAM Memory Needed 1GB N/A N/A
EDGEDR-64-N-231 EDGED-11-N-231 EDGED-32-N-231
Run applications designed with the same IDE Supported N/A N/A
Run as a service Supported N/A N/A
Email (SMTP Client) Supported N/A N/A
Create tags programmatically during the runtime Supported N/A N/A
Create screens programmatically during the runtime Supported N/A N/A
Create reports in PDF format Supported N/A N/A
Built-in functions Supported N/A N/A
Tag integration (Shared Tags) Supported N/A N/A
EDGEDR-64-N-231 EDGED-11-N-231 EDGED-32-N-231
Project Tags, System Tags, Classes and Arrays Supported N/A N/A
Security system Supported N/A N/A
Procedures Supported N/A N/A
Event logger Supported N/A N/A
Translation Supported N/A N/A
EDGEDR-64-N-231 EDGED-11-N-231 EDGED-32-N-231
Alarms Supported N/A N/A
Trend Logger Supported N/A N/A
Native Integration with AVEVA System Platform Supported N/A N/A
Native Integration with AVEVA Historian (on premise) Supported N/A N/A
Native Integration with AVEVA Insight (on the cloud) Supported N/A N/A
Recipes Supported N/A N/A
Reports Supported N/A N/A
ODBC Supported N/A N/A
Math Supported N/A N/A
Script Supported N/A N/A
Scheduler Supported N/A N/A
Database/ERP Supported N/A N/A
Azure IoT Hub Supported (2023) N/A N/A
EDGEDR-64-N-231 EDGED-11-N-231 EDGED-32-N-231
Drivers Supported N/A N/A
OPC DA 2.5 Client Supported

OPC DA 2.5 Client: Supported

Starting with this release, OPC DA Client (legacy) is disabled by default in new projects, though projects created in previous versions that use OPC DA Client (legacy) will function.

 		N/A N/A
OPC DA 2.5 Server Supported N/A N/A
OPC XML/DA Client Supported N/A N/A
OPC UA Client Supported N/A N/A
OPC UA Server Supported N/A N/A
TCP/IP Client Supported N/A N/A
TCP/IP Server Supported N/A N/A
Mobile Access Runtime Supported N/A N/A
OPC HDA Server Supported N/A N/A
EDGEDR-64-N-231 EDGED-11-N-231 EDGED-32-N-231
Screens Supported N/A N/A
Screen Group Supported N/A N/A
Graphic Script Supported N/A N/A
Local Viewer Supported N/A N/A
Server for SMA Thin Clients (HTML5) Supported N/A N/A
Server for Secure Viewer Thin Clients Supported N/A N/A
Server for Web Thin Clients Supported N/A N/A
Support for CGI Web Servers Supported (8,0) N/A N/A
Screen Scripts Supported N/A N/A
Shapes Supported N/A N/A
Active Objects Supported N/A N/A
Data Objects (Alarm/Event, Trend, Grid) Supported N/A N/A
Libraries – Project Symbols Supported N/A N/A
Libraries – Linked Pictures Supported N/A N/A
Libraries – .NET Controls Supported N/A N/A
Libraries – ActiveX Controls Supported N/A N/A
Libraries – Custom Widgets Supported (8.0+SP1) N/A N/A
Auto Screen Scaling Supported N/A N/A
Fill Effects Supported N/A N/A
Background Picture Supported N/A N/A
Ellipse Style Types Supported N/A N/A
Hint (Tooltip) Supported N/A N/A
Command Events Supported N/A N/A
Rotation Animation Supported N/A N/A
Trend Control > Export to file Supported N/A N/A
Trend Control > Points > Pen Style > Fill Supported N/A N/A
Enhanced Graphics (Anti-Aliasing, Gradual Transparency) Supported N/A N/A
Multi-Touch Gestures Supported N/A N/A
Industrial Graphics Supported with Limitations N/A N/A
