OMI6816B
-
- 1366 x 768 Resolution
- Intel® Pentium® N4200 1.1GHz Quad Core Processor
- 4GB RAM, 64GB up to 1TB MLC SSD
- Microsoft Windows® 10 IoT Ent Embedded 64-bit
- Additional Storage and Wi-Fi Kit upgrades available
- Aluminum Enclosure, VESA or Panel Mount
- Integrate with AVEVA™ Edge
15.6" Intel® Pentium® Panel PC with Windows®10 IoT OS
OMI6816B
As part of our Panel PC Series, this 15.6”, UL-certified IPC comes standard with a Windows® 10 IoT OS which supports most 3rd party and SCADA software like FactoryTalk® or our Aveva Edge®. Industrial grade components, high-quality construction, resistive touchscreen, and a fanless cooling system make the OMI6816B an ideal industrial computer for most industrial applications.
- Volume Discounts available. Contact Sales for more details.
- Customize your product with your company logo. Minimum quantities apply.
- US Based Technical Support
System
| Memory (RAM) | Onboard DDR3L 4 GB 1600 MHz |
| System Chipset | SoC |
| Solid State Drive Type | 1 x 2.5” SATA III, MLC |
| Solid State Drive Capacity | 64, 128, 256, 512 GB, 1TB SSD |
| Input Current | 0.92-3.67 A |
| Capacity (Screens) | 500 |
I/O Ports
| Serial Ports | 2 |
| Ethernet/LAN | 2 x GbE RJ-45 |
| Audio Output | 1 x 3.5 mm line out |
| SD Card Slot | 1 x internal micro Secure Digital memory card socket, up to 32 GB |
| Remote Power Switch | 2-pin connector header |
| Power | 3-pin connector header, DC power input |
| USB 3.0 Type A | 2 |
| Serial Options | 1 x RS-232/422/485 DE-9P, COM1 (default RS-232), 1 x RS-232 DE-9P, COM2 |
| Expansion Option | Optional Wi-Fi kit (IEEE 802.11a/b/g/n/ac card and antenna) |
Display
| Display Size | 15.6” WXGA TFT LCD |
| Resolution | 1366 x 768 |
| Luminance (cd/m^2) | 300 |
| Contrast Ratio | 500:1 |
| Backlight Lifetime (hrs) | 50000 |
| Colors | 16.7 M |
| View Angle (H° V°) | 160/160 |
Touch Screen
| Touch Interface | USB |
| Light Transmission | 80+% |
| Optical Bonding | No |
| Touch Screen Type | 5-Wire Resistive Touch |
Electrical
| Input Power | 33 W |
| Input Voltage | 9-36 VDC |
Mechanical
| Enclosure Material | Silver aluminum front bezel and chassis |
| Dimensions WxHxD | 16.23 x 10.93 x 2.37” [412 x 277.5 x 60.4 mm] |
| Panel Cutout (inches) [mm] | 15.51 x 10.24 [394 x 260 ] |
| Weight | ~ 10.58 lbs [4.8 kg] |
| Mounting | Panel mounting, VESA 100 x 100 mm |
Environmental
| Storage Temperature | -22~158°F [-30~70°C] |
| Operating Temperature | 32~122°F [0~50°C] |
| Relative Humidity | 10 to 90% @ 40°C, non-condensing |
Certification
| NEMA Rating | NEMA 4 when panel mounted |
| IP Rating | IP66 |
| CE | Yes |
| UL | Yes |
| ATEX | No |
| RoHS | Yes |
| FCC | Yes |
