OMI6808B

    • 800×600 Resolution
    • Intel® Pentium® N4200 1.1GHz Quad Core Processor
    • 4GB RAM, 64GB or 128GB MLC SSD
    • Microsoft Windows® 10 IoT Ent Embedded 64-bit, upgrades available
    • Additional Storage and Wi-Fi Kit upgrades available
    • Aluminum Enclosure, VESA or Panel Mount
    • Integrate with AVEVA Edge

8.0" Intel® Pentium® Panel PC with Windows®10 IoT OS

OMI6808B

$1,500

Configure your PC

The base options are selected by default. Select the options to get the desired configuration.

Reset Configuration
Current Configuration
Base Price
OMI6808B
$1500.00
Display
Included
Processor
Included
System Memory
Included
Storage
Included
Operating System
Included
Expansion Kit
Included

Part Number:

Buy Now

With a solid state platform and fanless cooling system, this 8” resistive touchscreen IPC is ideal for space-constrained applications.The OMI6808B provides a high-quality option for applications requiring UL and a Windows® Operating System. With Windows® 10 IoT, this industrial computer supports 3rd party and SCADA software like FactoryTalk® or our Aveva Edge ®.

Specifications

System

Memory (RAM)

Onboard DDR3L 4 GB 1600 MHz

System Chipset

SoC

Solid State Drive Type

1 x 1.8” SATA II, MLC

Solid State Drive Capacity

64, 128 GB SSD

Input Current

0.78-3.11 A

Capacity (Screens)

500

I/O Ports

Serial Ports

2

Ethernet/LAN

2 x GbE RJ-45

Audio Output

1 x 3.5 mm line out

SD Card Slot

1 x internal micro Secure Digital memory card socket, up to 32 GB

Remote Power Switch

2-pin connector header

VGA

No

Power

3-pin connector header, DC power input

USB 3.0 Type A

2

Serial Options

1 x RS-232/422/485 DE-9P, COM1 (default RS-232), 1 x RS-232 DE-9P, COM2

Expansion Option

Optional Wi-Fi kit (IEEE 802.11a/b/g/n/ac card and antenna)

Display

Display Size

8.0” SVGA TFT LCD

Resolution

800 x 600

Luminance (cd/m^2)

350

Contrast Ratio

500:1

Backlight Lifetime (hrs)

40000

Colors

16.2 M

View Angle (H° V°)

140/120

Touch Screen

Touch Interface

USB

Light Transmission

80+%

Optical Bonding

No

Digital I/O Port

N/A

Touch Screen Type

5-Wire Resistive Touch

Electrical

Input Power

28 W

Input Voltage

9-36 VDC

Mechanical

Enclosure Material

Silver aluminum front bezel and chassis

Dimensions WxHxD

9.09 x 6.93 x 1.97” [231 x 176 x 50 mm]

Panel Cutout (inches) [mm]

8.74 x 6.57 [222 x 167 ]

Weight

~ 4.19 lbs [1.9 kg]

Mounting

Panel mounting, VESA 75 x 75 mm

Environmental

Storage Temperature

-22~158°F [-30~70°C]

Operating Temperature

32~122°F [0~50°C]

Relative Humidity

10 to 90% @ 40°C, non-condensing

Certification

NEMA Rating

NEMA 4 when panel mounted

IP Rating

IP66

CE

Yes

UL

Yes

ATEX

No

RoHS

Yes

FCC

Yes

Available Software

Documentation & Resources

Need Additional Support?

Maple Systems
808 134th St. SW, Suite 120
Everett, WA 98204

Phone: 425.745.3229
Fax: 425.745.3429
Email: sales@maplesystems.com

Business Hours:
Monday – Friday 6:00am – 4:30pm (PST)

What's Included

When you order the OMI6808B the following items are included in the box:

  • OMI6808B Industrial Panel PC
  • Warranty Statement
  • Installation Instruction
  • Product Flyer
  • DC Power Connector
  • DC Power Adapter with cord
  • 2-Pin Remote Power Switch connector
  • Mounting Kit (Quantity determined by screen size)
