4.3" Dual-Ethernet Advanced HMI with CODESYS
$530.00
The cMT2058XH with activated CODESYS license is a powerful HMI with dual Ethernet, remote access, and IIoT functionality. Pair this operator interface with our remote IO and CODESYS license for soft PLC functionality.
Try Before You Buy: Follow along to learn how EBPro, our 100% free HMI configuration software, allows you to develop and simulate your HMI program entirely free of charge.
- Compare cMT2058XH-CODESYS and other models.
- Volume discounts available.
- Customize product with your company logo. Minimum quantities apply.
- Connect to +400 PLCs and Controllers.
- US-based technical support.
Share the product:
cMT2058XH-CODESYS Highlights
- TFT LCD with 800 x 480 Pixel Resolution
- Quad-Core RISC CPU
- 2 Ethernet, 1 USB, 2 Serial Ports
- MQTT, Sparkplug B, WebView, VNC
- Add an EasyAccess2.0 license for remote access
- Pair with our remote IO for CODESYS functionality
- UNBRANDED
System
| CPU | Quad-Core RISC |
| Memory (RAM) | 1 GB |
| Memory (Flash) | 4 GB |
| RTC | Built-in |
| Programming Software | EBPro (Latest Version) |
I/O Ports
| Ethernet/LAN | 1 x 10/100 Base-T RJ-45, 1 x GbE RJ-45 |
| CANbus | N/A |
| Audio Output | N/A |
| SD Card Slot | N/A |
| USB Host Ports | USB 2.0 x 1 |
| USB Client Ports | N/A |
| Wi-Fi | N/A |
| COM Port | 1 x DE9P COM1: RS-232/RS-485 2 or 4 wire, COM 3: RS-485 2 wires |
| Local bus | N/A |
| HDMI Port | N/A |
| Video Input | N/A |
| Serial Ports | 1 |
Display
| Display Size | 4.3" WVA LCD |
| Resolution | 800 x 480 |
| Luminance (cd/m^2) | 530 |
| Contrast Ratio | 800:1 |
| Backlight Type | LED |
| Backlight Lifetime (hrs) | 30,000+ |
| Colors | 16.7 M |
| Display Type | 4.3" WVA |
| Viewing Angle (H°/V°) | 160/160 |
| Size (W x H) | 3.74 x 2.13 inches [95 x 54 mm] |
Touch Screen
| Type | 4-wire resistive touch |
| Accuracy | Length (x)±2%, Width(y)±2% |
| Touch Panel Hardness Scale | N/A |
Electrical
| Input Power | 12.2 W |
| Power Isolation | Built-in |
| Power Dissipation | N/A |
| Current for Internal Bus | N/A |
| Current Consumption | N/A |
| Isolation Resistance | Exceed 50 MO – @ 500 VDC |
| Input Voltage | 24 ± 20% VDC |
| Input Current | 510 mA @ 24 VDC |
Mechanical
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| Enclosure Material | Plastic, charcoal grey |
| PCB Coating | Yes |
| Dimensions WxHxD | 5.04 x 4.02 x 1.26 inches [128 x 102 x 32 mm] |
| Panel Cutout (inches) [mm] | 4.69 x 3.66 [119 x 93] |
| Weight | Approx. 0.6 lbs. [0.27 kg] |
| Mounting | Panel mount |
Environmental
| Operating Temperature | 32° ~ 122°F (0° ~ 50°C) |
| Storage Temperature | -4° ~ 140°F (-20° ~ 60°C) |
| Relative Humidity | 10% ~ 90% (non-condensing) |
Certification
| CE UKCA | Yes |
| UL Type Rating | UL Type 4X (indoor use only) |
| NEMA Rating | NEMA4 |
| IP Rating | IP66 Compliant Front Panel |
| CE | Yes |
| UL | cULus Listed |
| Class 1 Div 2 | N/A |
| ATEX | N/A |
| RoHS | Yes |
Unboxing a cMT2058XH
We'll unbox, show the accessories that come in the box, power it up and load a demo project.
FREE User Friendly HMI Software
Download our free, full-featured HMI configuration software to create custom control applications for your industrial process. EBPro supports over 300 PLC & controller protocols, ensuring seamless integration with new or existing systems. No license or key required.
Documents
Manuals
- EBPro Programming Manual
- EBPro Quick Start Guide
- EasyWeb 2.0 Operations Manual
- cMT Quick Start Guide
- CMT2058XH Installation Guide
- CODESYS Quick-Start Guide
- Activate CODESYS on cMT Models
Certifications
- CE UK Declaration of Conformity – cMT2058XH, cMT2058XHW
- UL-cMT Series
- RoHS all series
- REACH Certification
- EU Declaration of Conformity (Battery Regulations)
- Trade Agreement Act
- Russian Iron and Steel Declaration
- Country of Origin Certification
CAD Files
When you order the cMT2058XH-CODESYS the following items are included in the box:
- cMT2058XH Touchscreen HMI with CODESYS License Activated
- Warranty Statement
- Installation Instruction
- Power Connector
- Mounting Clips
