10.1" Intel Celeron Stainless Steel Industrial Panel PC
$2,000.00
The PCS6810AP provides power, performance and functionality in one package. With 304 stainless steel housing and IP66/IP69K protection when panel mounted for dust and water resistance, this 10.1” IPC is ready for high-pressure, high-temperature washdowns. Designed for industries that require stringent disinfection processes and splashing cleanup routines found in Food, Beverage, Pharmaceutical and Chemical applications. As part of our powerful Industrial Panel PC Series, this industrial computer comes with either a Linux® or a Windows® OS which supports most 3rd party SCADA software like SIMATIC WinCC, Ignition, FactoryTalk®, & Aveva Edge®.
- Intel® Certified Gold Partner.
- Volume discounts available.
- Typically ships in 2 days.
- US-based technical support.
Share the product:
The base options are selected by default. Select the options to get the desired configuration.
System
| CPU | Intel® Celeron™ N2930 Quad-Core 1.83 GHz Processor |
| Memory (RAM) | Onboard DDR3L 4 GB 1600 MHz |
| System Chipset | SoC |
| Solid State Drive Type | 1 x 2.5” SATA III, MLC |
| Solid State Drive Capacity | 64, 128, 256, 512 GB, 1TB SSD |
I/O Ports
| Power | 3-pin connector header, DC power input |
| Ethernet/LAN | 2 x GbE RJ-45 |
| Audio Output | 1 x 3.5 mm line out |
| SD Card Slot | 1 x internal micro Secure Digital memory card socket, up to 32 GB |
| HDMI Port | No |
| Remote Power Switch | 2-pin connector header |
| Display Output | No |
| USB 3.0 Type A | 2 |
| Serial Ports | 2 |
| Serial Options | 1 x RS-232/422/485 DE-9P, COM1 (default RS-232), 1 x RS-232 DE-9P, COM2 |
| Expansion Option | Optional Wi-Fi kit (IEEE802.11ax card and antenna), Bluetooth 5.2 Support |
Display
| Display Size | 10.1” WXGA TFT LCD |
| Resolution | 1280 x 800 |
| Luminance (cd/m^2) | 350 |
| Contrast Ratio | 800:1 |
| Backlight Lifetime (hrs) | 30,000+ |
| Colors | 16.7 M |
| View Angle (H° V°) | 170/170 |
Touch Screen
| Touch Interface | USB |
| Light Transmission | 90+% |
| Optical Bonding | No |
| Touch Screen Type | Projected Capacitive |
Electrical
| Input Power | 20 W |
| Input Voltage | 9~36 VDC |
| Input Current | 0.56 – 2.22 A |
Mechanical
| Enclosure Material | 304 Stainless Steel Front Bezel and Aluminum Chassis |
| Dimensions WxHxD | 11.65 x 7.87 x 1.85” [296 x 200 x 46.9 mm] |
| Panel Cutout (inches) [mm] | 10.71 x 6.93 [272 x 176 ] |
| Weight | ~ 5.51 lbs [2.5 kg] |
| Mounting | Panel mounting, VESA 100 x 100 mm |
Environmental
| Operating Temperature | 32~122°F [0~50°C] |
| Storage Temperature | -22~158°F [-30~70°C] |
| Relative Humidity | 10 to 90% @ 40°C, non-condensing |
Certification
| NEMA Rating | NEMA 4 when panel mounted |
| IP Rating | IP66/IP69K |
| CE | Yes |
| UL | No |
| ATEX | No |
| RoHS | Yes |
| FCC | FCC Class A |
PCS6800 Series Unboxing
We'll review what comes with the PC, the I/O ports and some features, and other sizes we offer.
Capacitive/Glove Friendly
Our Rugged, Industrial Panel PCs with Capacitive Touchscreens are Glove Friendly, watch as we demonstrate with our OMI6900 Series Panel PC.
- Linux
- Windows
- SCADA – AVEVA
Documents
Manuals
Certifications
- REACH Certification
- CE-PCS6800 Series
- RoHS all series
- Trade Agreement Act
- FCC-PCS6800_AEx_MON6000-Series
- Country of Origin Certification
CAD Files
When you order the PCS6810AP the following items are included in the box:
- PCS6810AP Industrial Panel PC
- Warranty Statement
- Installation Instruction
- Product Flyer
- DC Power Connector
- DC Power Adapter with cord
- 2-Pin Remote Power Switch connector
- Mounting Kit (Quantity determined by screen size)
