PLC-ES0808P
- Supports flexible expansion up to 11 I/O modules
- Built-in 8 Digital Inputs (Sink/Sourcing) and 8 Digital Outputs (Sourcing)
- SD-Card for project / Firmware Download
- PID Control with Auto-Tuning
- 2 High Speed Counter (HSC) Inputs – up to 20kHz
- 2 Pulse Train Output (PTO) Channels – up to 100KHz
- Serial and Ethernet Communication
Expansion IO Modules
Modular CPU
PLC-ES0808P
$320.00
Compact PLC, high performance, built-in functions (PID control, high speed counter, and positioning) for medium and small-scale systems with ethernet or serial communication.
Contact sales@maplesystems.com or click “Schedule a Call Now” to schedule a 30-min PLC kick-off call with one of our account managers!
Try Before You Buy: Follow along to learn how MapleLogic, our 100% free PLC control software, allows you to develop and simulate your PLC program entirely free of charge.
- Volume discounts available. Contact sales for more details.
- US Based Technical Support
Share the product:
Review this product
Share your thoughts with other customers about this product
Functional
| Program Languages | Ladder (LD), Instruction List (I/L), Function Block (FB), Sequential Function Chart (SFC) |
| Power Consumption | 12 W, 12/24 VDC, 0.5 A at 24 VDC |
| High-Speed Counter (HSC) | Yes |
| Positioning | Yes |
| Number of Channels | 16 Total: 8 Digital Inputs, 8 Digital Outputs |
| Program Memory | 10K STEP |
| Execution Speed | 300ns/STEP |
| Number of IO Points | 384 (maximum) |
Digital I/O
| Digital Input Type | TR Sink/Source |
| Digital Output Type | TR Source |
| Rated Digital Input Voltage | 24 VDC (12 or 24 VDC is used for HSC) |
| Rated Digital Output Voltage | 12/24 VDC |
| Rated Digital Output Current | 1 point = 0.2 A, 1 COM = 2 A |
| Digital Output Insulation Method | Photocoupler |
| Digital Input Insulation Method | Photocoupler |
| Rated Digital Input Current | 4 mA |
I/O Ports
| USB | USB 2.0 (Mini-B) x 1 |
| Ethernet/LAN | 10/100 Base-T x 1 |
| SD Card Slot | N/A |
| Serial | 1 x RS232, 1x RS422/RS485 |
Mechanical
| Dimensions WxHxD | 91 x 30 x 64 mm (3.6 x 1.2 x 2.5 in) |
| Weight | 155 g (0.34 lb) |
| Shock | 15G |
| Vibration | 0.5G Continuous, 1G Discontinuous |
| Square Wave Impulse Noise | ±2 kV |
| ESD Immunity | ±4 kV – Contact Discharges, ±8 kV – Air Discharges |
| Radiated Electromagnetic Immunity | 80–1000 MHz, 10 V/m |
| Surge Transient Immunity | 2 kV – CPU, Power; 2 kV – Digital I/O (VAC); 1 kV – Digital I/O (VDC); 1 kV – Communication |
Environmental
| Storage Temperature | -25 – 80 °C (-13 – 176 °F) |
| Operating Temperature | -10 – 60 °C (14 – 140 °F) |
| Operating/Storage Relative Humidity | 5 – 95% Non-condensing |
Certification
| CE | Yes |
| UL | cULus Listed |
| RoHS | Yes |
Connect a Maple Systems HMI to a Maple Systems PLC
Whether you are new to Maple Systems or know our HMIs well, pairing one of our powerful HMIs with a low-cost PLC is easy.
Unboxing PLC-ES0808P
Explore the key features of PLC-ES0808P to get a clear overview of what to expect from this product.
Customers who bought this product also bought:
-
Power Supply, Single Output, DIN Rail, 24VDC, 2.5A.$50.00 -
Cable, Main CPU, 5 ft.$40.00 -
Cable, I/O 32pts, 5 ft.$35.00
FREE User Friendly PLC Software
Download our free, powerful PLC configuration software. Using your preferred programming language—Ladder Diagram, Instruction List, Sequential Function Chart, or Function Block—you can create your project, your way, for a one-of-a-kind control solution.
Documents
Manuals
- MapleLogic User Manual
- Modular CPU Modules User Manual
- MapleLogic PID User Manual
- MapleLogic Positioning User Manual
Certifications
CAD Files
When you order the PLC-ES0808P the following items are included in the box:
- PLC-ES0808P
- Product Manual
