AVEVA™ Edge HMI/SCADA – Runtime license, 16,000 tags, 1 Thin Client – New License
$3,996.00
- HMI/SCADA Full Version
- 1 Runtime License Included
- 16,000 Tags, 1 Thin Client
- Softkey Only, Hardkey Sold Separately
This package includes one HMI/SCADA Full Version, Runtime Only license, with support for one Thin Client connected to the runtime station (Server). All license levels support an unlimited number of communication drivers (limited by operating system and hardware). Softkey only. Physical activation number by request only, additional charges may apply.
- US-based technical support.
Share the product:
Licensing
| License Type | SCADA (Full Version) – Runtime Only |
| Number of Tags | 16,000 |
| Number of Supported Thin Clients | Unlimited |
| License Server | Supported |
| USB Hardkey | Supported |
Operating System
| Windows Server 2022 | Supported |
| Windows Server 2019 | Supported |
| Windows Server 2016 | Supported |
| Windows 11 | Supported |
| Windows 10 | Supported |
| Windows 11 IoT Enterprise | Supported |
| Windows 10 IoT Enterprise (LTSC/LTSB) | Supported |
| Linux (x86/arm) | Not Supported |
System Requirements
| Minimum Free Storage Memory Needed | 12GB |
| Minimum Free RAM Memory Needed | 1GB |
General
| Run applications designed with the same IDE | Supported |
| Run as a service | Supported |
| Email (SMTP Client) | Supported |
| Create tags programmatically during the runtime | Supported |
| Create screens programmatically during the runtime | Supported |
| Create reports in PDF format | Supported |
| Built-in functions | Supported |
| Tag integration (Shared Tags) | Supported |
Global
| Project Tags, System Tags, Classes and Arrays | Supported |
| Security system | Supported |
| Procedures | Supported |
| Event logger | Supported |
| Translation | Supported |
Tasks
| Alarms | Supported |
| Trend Logger | Supported |
| Native Integration with AVEVA System Platform | Supported |
| Native Integration with AVEVA Historian (on premise) | Supported |
| Native Integration with AVEVA Insight (on the cloud) | Supported |
| Recipes | Supported |
| Reports | Supported |
| ODBC | Supported |
| Math | Supported |
| Script | Supported |
| Scheduler | Supported |
| Database/ERP | Supported |
| Azure IoT Hub | Supported (2023) |
Communication
| Drivers | Supported |
| OPC DA 2.5 Client | Supported |
| OPC DA 2.5 Server | Supported |
| OPC XML/DA Client | Supported |
| OPC UA Client | Supported |
| OPC UA Server | Supported |
| TCP/IP Client | Supported |
| TCP/IP Server | Supported |
| Mobile Access Runtime | Supported |
| OPC HDA Server | Supported |
Graphical Interface
| Screens | Supported |
| Screen Group | Supported |
| Graphic Script | Supported |
| Local Viewer | Supported |
| Server for SMA Thin Clients (HTML5) | Supported |
| Server for Secure Viewer Thin Clients | Supported |
| Server for Web Thin Clients | Supported |
| Support for CGI Web Servers | Supported (8,0) |
| Screen Scripts | Supported |
| Shapes | Supported |
| Active Objects | Supported |
| Data Objects (Alarm/Event, Trend, Grid) | Supported |
| Libraries – Project Symbols | Supported |
| Libraries – Linked Pictures | Supported |
| Libraries – .NET Controls | Supported |
| Libraries – ActiveX Controls | Supported |
| Libraries – Custom Widgets | Supported (8.0+SP1) |
| Auto Screen Scaling | Supported |
| Fill Effects | Supported |
| Background Picture | Supported |
| Ellipse Style Types | Supported |
| Hint (Tooltip) | Supported |
| Command Events | Supported |
| Rotation Animation | Supported |
| Trend Control > Export to file | Supported |
| Trend Control > Points > Pen Style > Fill | Supported |
| Enhanced Graphics (Anti-Aliasing, Gradual Transparency) | Supported |
| Multi-Touch Gestures | Supported |
| Industrial Graphics | Supported with Limitations |
