AVEVA™ Edge – Runtime Only: Embedded, 300 tags, 1 Thin Client

EDGEEH-30-N-23
— Leave a Review
$623.00
  • Embedded HMI/Win 10 IoT
  • 1 Runtime License Included
  • 300 Tags, 1 Thin Client
  • Softkey Only, Hardkey Sold Separately

Compare Embedded version (Windows) with Full Version and IoT View (Linux or Non-Windows) versions

This package includes one Runtime Only license, with support for one Thin Client connected to the runtime station (Server). All license levels support an unlimited number of communication drivers (limited by operating system and hardware). Softkey only. Physical activation number by request only, additional charges may apply.

Share the product:
  • Aveva Edge 300-Tag Embedded HMI Runtime License for Maple Systems IPCs and Panel PCs
Aveva Edge 300-Tag Embedded HMI Runtime License for Maple Systems IPCs and Panel PCs

Media Gallery

AVEVA™ Edge – Runtime Only: Embedded, 300 tags, 1 Thin Client

  • Aveva Edge 300-Tag Embedded HMI Runtime License for Maple Systems IPCs and Panel PCs
Aveva Edge 300-Tag Embedded HMI Runtime License for Maple Systems IPCs and Panel PCs

  • Embedded HMI/Win 10 IoT
  • 1 Runtime License Included
  • 300 Tags, 1 Thin Client
  • Softkey Only, Hardkey Sold Separately

This product:
Total price: N/A

Licensing

License Type
Windows Embedded Standard (Win 10 IoT/Win 11 IoT) – Runtime Only
Number of Tags
300
Number of Supported Thin Clients
Unlimited

Number of Supported Thin Clients: Unlimited

Limited by license and external and physical constraints (hardware and operating system).

License Server
Not Supported
USB Hardkey
Supported with Limitations

USB Hardkey: Supported with Limitations

The hardware from the WiBu manufacturer is supported by all Runtime Editions (excluding IoT View)

Operating System

Windows Server 2022
Not Supported
Windows Server 2019
Not Supported
Windows Server 2016
Not Supported
Windows 11
Not Supported
Windows 10
Not Supported
Windows 11 IoT Enterprise
Supported
Windows 10 IoT Enterprise (LTSC/LTSB)
Supported
Linux (x86/arm)
Not Supported

System Requirements

Minimum Free Storage Memory Needed
128MB
Minimum Free RAM Memory Needed
64MB

General

Run applications designed with the same IDE
Supported
Run as a service
Not Supported
Email (SMTP Client)
Supported
Create tags programmatically during the runtime
Not Supported
Create screens programmatically during the runtime
Not Supported
Create reports in PDF format
Not Supported
Built-in functions
Supported with limitations

Built-in functions: Supported with limitations

The vast majority of the built-in functions are supported by all Runtime Editions. However, specific functions are Not supported on specific platforms. The complete reference is available in the Technical reference manual at "Appendix: Built-in Scripting Language > List of available functions"

Tag integration (Shared Tags)
Supported (2023)

Global

Project Tags, System Tags, Classes and Arrays
Supported
Security system
Supported
Procedures
Supported
Event logger
Supported
Translation
Supported

Tasks

Alarms
Supported
Trend Logger
Supported
Native Integration with AVEVA System Platform
Supported
Native Integration with AVEVA Historian (on premise)
Supported
Native Integration with AVEVA Insight (on the cloud)
Supported
Recipes
Supported
Reports
Supported
ODBC
Supported with Limitations

ODBC: Supported with Limitations

Even though the ODBC worksheets (legacy) are not supported, the Database/ERP worksheets are supported.

Math
Supported
Script
Supported
Scheduler
Supported
Database/ERP
Supported
Azure IoT Hub
Not Supported

Communication

Drivers
Supported with Limitations

Drivers: Supported with Limitations

The vast majority of the native communication drivers are supported by many runtime editions. However, specific native drivers are not supported on specific platforms. The complete reference is available through the actual product (Project Explorer > Comm > Drivers > Add/Remove Drivers). Moreover, IoT View supports main driver sheets only.

OPC DA 2.5 Client
Supported

OPC DA 2.5 Client: Supported

Starting with this release, OPC DA Client (legacy) is disabled by default in new projects, though projects created in previous versions that use OPC DA Client (legacy) will function.

OPC DA 2.5 Server
Supported
OPC XML/DA Client
Not Supported
OPC UA Client
Supported
OPC UA Server
Supported
TCP/IP Client
Supported
TCP/IP Server
Supported
Mobile Access Runtime
Supported
OPC HDA Server
Not Supported

Graphical Interface

Screens
Supported
Screen Group
Supported
Graphic Script
Supported
Local Viewer
Supported
Server for SMA Thin Clients (HTML5)
Supported
Server for Secure Viewer Thin Clients
Supported
Server for Web Thin Clients
Supported
Support for CGI Web Servers
Supported (8,0)
Screen Scripts
Supported
Shapes
Supported
Active Objects
Supported
Data Objects (Alarm/Event, Trend, Grid)
Supported
Libraries – Project Symbols
Supported
Libraries – Linked Pictures
Supported
Libraries – .NET Controls
Not Supported
Libraries – ActiveX Controls
Supported
Libraries – Custom Widgets
Supported (8.0+SP1)
Auto Screen Scaling
Supported with Limitations

Auto Screen Scaling: Supported with Limitations

The screens can be converted to a different resolution by using the command "Home > Convert resolution"

Fill Effects
Supported with Limitations

Fill Effects: Supported with Limitations

Fill effects are supported for rectangle objects.

Background Picture
Supported with Limitationis

Background Picture: Supported with Limitationis

The following formats are supported: BMP, JPG, and PNG, as long as the image of the device supports these formats as well.

Ellipse Style Types
Supported with Limitations

Ellipse Style Types: Supported with Limitations

The style type Ellipse is supported, but the style types Arc, Chord, and Ring are not supported.

Hint (Tooltip)
Supported with Limitations

Hint (Tooltip): Supported with Limitations

The Hint field will update the Hint System Tag. The graphical tooltip will not be automatically displayed on Compact HMI runtime nor SMA Thin Clients.

Command Events
Supported with Limitations

Command Events: Supported with Limitations

The Command events "On Down", "While Down", and "On Up" are supported. The remaining command events are not supported.

Rotation Animation
Supported with Limitations

Rotation Animation: Supported with Limitations

The Rotation Animation is supported for closed polygons, but not for pictures.

Trend Control > Export to file
Not Supported
Trend Control > Points > Pen Style > Fill
Not Supported
Enhanced Graphics (Anti-Aliasing, Gradual Transparency)
Not Supported
Multi-Touch Gestures
Supported with Limitations

Multi-Touch Gestures: Supported with Limitations

Compact HMI does not support "Zoom and Pan gestures on project screens" and "Gestures with Rotation Animation".

Industrial Graphics
Not Supported
