AVEVA™ Edge IoT View – Runtime license, 150 tags, 1 Thin Client – New license

EDGEIV-15-N-23
— Leave a Review
$242.00
  • IoT View – Linux or Non-Windows Operating System
  • 1 Runtime License Included
  • 150 Tags, 1 Thin Client (Runtime only)
  • Softkey Only, Hardkey Sold Separately

Compare IoT View (Linux or Non-Windows) with Embedded version (Windows), and Full versions

Share the product:
  • Aveva Edge 150-Tag IoT View Runtime License for Maple Systems IPCs and Panel PCs
Aveva Edge 150-Tag IoT View Runtime License for Maple Systems IPCs and Panel PCs

Media Gallery

AVEVA™ Edge IoT View – Runtime license, 150 tags, 1 Thin Client – New license

  • Aveva Edge 150-Tag IoT View Runtime License for Maple Systems IPCs and Panel PCs
Aveva Edge 150-Tag IoT View Runtime License for Maple Systems IPCs and Panel PCs

  • IoT View – Linux or Non-Windows Operating System
  • 1 Runtime License Included
  • 150 Tags, 1 Thin Client (Runtime only)
  • Softkey Only, Hardkey Sold Separately

This product:
Total price: N/A

Licensing

License Type
IoT View (Linux or Non-Windows OS) – Runtime Only
Number of Tags
150
Number of Supported Thin Clients
Unlimited

Number of Supported Thin Clients: Unlimited

Limited by license and external and physical constraints (hardware and operating system).

License Server
Not Supported
USB Hardkey
Not Supported

Operating System

Windows Server 2022
Not Supported
Windows Server 2019
Not Supported
Windows Server 2016
Not Supported
Windows 11
Not Supported
Windows 10
Not Supported
Windows 11 IoT Enterprise
Not Supported
Windows 10 IoT Enterprise (LTSC/LTSB)
Not Supported
Linux (x86/arm)
Supported

System Requirements

Minimum Free Storage Memory Needed
140MB
Minimum Free RAM Memory Needed
32MB

General

Run applications designed with the same IDE
Supported
Run as a service
Not Supported
Email (SMTP Client)
Supported
Create tags programmatically during the runtime
Not Supported
Create screens programmatically during the runtime
Not Supported
Create reports in PDF format
Not Supported
Built-in functions
Supported with limitations (8.0)

Built-in functions: Supported with limitations (8.0)

The vast majority of the built-in functions are supported by all Runtime Editions. However, specific functions are Not supported on specific platforms. The complete reference is available in the Technical reference manual at "Appendix: Built-in Scripting Language > List of available functions"

Tag integration (Shared Tags)
Supported (2023)

Global

Project Tags, System Tags, Classes and Arrays
Supported (8.0)
Security system
Supported with limitations (8.0)

Security system: Supported with limitations (8.0)

LDAP and Local Plus are supported: Distributed mode is not

Procedures
Supported (2023 R2)

Procedures: Supported (2023 R2)

Python only

Event logger
Supported with limitations (2020R2)

Event logger: Supported with limitations (2020R2)

Event history can be saved to Proprietary and Database formats

Translation
Supported

Tasks

Alarms
Supported with limitations (2020R2)

Alarms: Supported with limitations (2020R2)

Alarm Online and Alarm History supported. Alarm history can be saved to Proprietary and Database formats.

Trend Logger
Supported with limitations (2020R2)

Trend Logger: Supported with limitations (2020R2)

Trend Logger history can be saved to Proprietary, Database, and Historian (AVEVA Insight CSV/JSON) and AVEVA Historian on-premises. (2020R2 SP1)

Native Integration with AVEVA System Platform
Supported with limitations (2020R2)

Native Integration with AVEVA System Platform: Supported with limitations (2020R2)

Native integration through the ITMEViewApp object for AVEVA System Platform is available for AVEVA Edge SCADA and AVEVA Edge Embedded HMI only. Integration via MQTT SparkplugB (requiring a third-party MQTT Broker) is available for AVEVA Edge SCADA, AVEVA Edge Embedded HMI, and AVEVA Edge IoT View.

Native Integration with AVEVA Historian (on premise)
Supported (2020R2 SP1)
Native Integration with AVEVA Insight (on the cloud)
Supported
Recipes
Not Supported
Reports
Not Supported
ODBC
Not Supported
Math
Supported with Limitations (8.0+SP1)
Script
Supported (2023 R2)

Script: Supported (2023 R2)

Python only.

Scheduler
Supported (2020R2)
Database/ERP
Supported with Limitations (8.0+SP1)

Database/ERP: Supported with Limitations (8.0+SP1)

Sub-set of DB/ERP functions supported. DB/ERP worksheet not supported

Azure IoT Hub
Not Supported

Communication

Drivers
Supported with Limitations (8.0)

Drivers: Supported with Limitations (8.0)

The vast majority of the native communication drivers are supported by many runtime editions. However, specific native drivers are not supported on specific platforms. The complete reference is available through the actual product (Project Explorer > Comm > Drivers > Add/Remove Drivers). Moreover, IoT View supports main driver sheets only.

OPC DA 2.5 Client
Not Supported
OPC DA 2.5 Server
Not Supported
OPC XML/DA Client
Not Supported
OPC UA Client
Supported
OPC UA Server
Supported
TCP/IP Client
Not Supported
TCP/IP Server
Not Supported
Mobile Access Runtime
Supported (8.0)
OPC HDA Server
Not Supported

Graphical Interface

Screens
Supported
Screen Group
Supported
Graphic Script
Not Supported
Local Viewer
Not Supported
Server for SMA Thin Clients (HTML5)
Supported (8.0)
Server for Secure Viewer Thin Clients
Not Supported
Server for Web Thin Clients
Not Supported
Support for CGI Web Servers
Supported (8,0)
Screen Scripts
Supported with Limitations (8.0)

Screen Scripts: Supported with Limitations (8.0)

Built-in language only

Shapes
Supported (8.0)
Active Objects
Supported with limitations (8.0)

Active Objects: Supported with limitations (8.0)

Push button, List box, and Smart message are supported now.

Data Objects (Alarm/Event, Trend, Grid)
Supported with Limitations (8.0+SP1)
Libraries – Project Symbols
Supported with Limitations (8.0)

Libraries – Project Symbols: Supported with Limitations (8.0)

Project Symbols are supported, as long as their shapes, active objects, and/or animations are supported by the target platform.

Libraries – Linked Pictures
Supported (8.0)
Libraries – .NET Controls
Not Supported
Libraries – ActiveX Controls
Not Supported
Libraries – Custom Widgets
Supported (8.0+SP1)
Auto Screen Scaling
Supported (8.0)
Fill Effects
Supported with Limitations (8.0)

Fill Effects: Supported with Limitations (8.0)

Fill effects are supported for rectangle objects.

Background Picture
Supported (8.0)
Ellipse Style Types
Supported with Limitations (8.0)

Ellipse Style Types: Supported with Limitations (8.0)

The style type Ellipse is supported, but the style type Arc, Chord, and Ring are not supported.

Hint (Tooltip)
Supported with Limitations (8.0)

Hint (Tooltip): Supported with Limitations (8.0)

The Hint field will update the Hint System Tag. The graphical tooltip will not be automatically displayed on Compact HMI runtime nor SMA Thin Clients.

Command Events
Supported with Limitations (8.0)

Command Events: Supported with Limitations (8.0)

The Command events "On Down", "While Down", and "On Up" are supported. The remaining command events are not supported.

Rotation Animation
Supported with Limitations

Rotation Animation: Supported with Limitations

The Rotation Animation is supported for closed polygons, but not for pictures.

Trend Control > Export to file
Not Supported
Trend Control > Points > Pen Style > Fill
Not Supported
Enhanced Graphics (Anti-Aliasing, Gradual Transparency)
Supported (8.0)
Multi-Touch Gestures
Not Supported
Industrial Graphics
Not Supported
