iR-DQ16-P

  • 16 Digital Outputs (PNP)

Digital IO Module | iR-DQ16-P

iR-DQ16-P

$119.00

Buy Now

Pair this I/O module with the cMT-CTRL01 PLC base, or  any qualifying cMT HMI and Communication Coupler combination to implement a control solution that utilizes CODESYS programming. Up to 16 modules can be added to create a highly functioning remote I/O block.

Specifications

Communication

Connection Cross-section

AWG 28-16

Digital Output

Total Number of Outputs

16

Output Logic

Source

Output Voltage

11~28VDC

Output Current

0.5A per channel (Max 4A)

Response Time

300μs

Current Consumption

196mA@5VDC

Mechanical

Enclosure Material

Plastic

PCB Coating

Yes

Dimensions WxHxD

27 x 109 x 81 mm

Mounting

35mm DIN rail mounting

Environmental

Storage Temperature

-20° ~ 70°C (-4° ~ 158°F)

Operating Temperature

0° ~ 55°C (32° ~ 131°F)

Relative Humidity

10% ~ 90% (non-condensing)

Certification

IP Rating

IP20

EMC Immunity

Conforms to EN 55032: 2012+AC: 2013, Class A EN 61000-6-4: 2007+A1:2011 EN 55024: 2010+A1: 2015 EN 61000-6-2:2005
