Intel Celeron powered Industrial PCs
Intel Celeron computers from Maple Systems combine the capabilities of Intel Celeron CPUs with industrial enclosures and components for high reliability.
Results
Sort by:
-
Featured
19.0″ C1D2, Stainless Steel, Wide-Temp, 1000nit Intel® Celeron® Industrial PC
AEx-819PH-- Intel Celeron N2930 Quad-core 1.83 GHz, Windows® 10 Operating System, Fanless
- 8 GB RAM, 1 x M12 8-pin for 2 x USB 2.0 type A, 2 x M12 8-pin for RJ-45, 1 x M12 3-pin for DC power, 1 x M12 12-pin for VGA, 1 M12 Serial Port
- 316 Stainless Steel Chassis, C1D2, C2D2, ATEX/ IECExx Zone 2/22, IP66, Extended Temperature -20~60°C
- 1000 nit High Brightness, 19” Capacitive Touchscreen, 1280 x 1024 Resolution, Optically Bonded
- VESA Mount
-
10.1″ Intel Celeron Stainless Steel Industrial Panel PC
PCS6810AP- Intel® Celeron N2930 Quad-Core 1.83 GHz Processor, Windows® or Linux® Operating System, Fanless
- 4 GB RAM, 2 x GbE RJ45 Ethernet Ports, 2 x USB 3.0 Type A Ports, 2 x Serial Ports, 1 Audio Out, Optional Wi-Fi
- 304 Stainless Steel Front Bezel, IP66K/IP69K, NEMA 4 when panel mounted, EN-1672-2 Certified
- Projected Capacitive 10.1″ Touchscreen, 1280 x 800 Resolution
- VESA or Panel Mount
-
10.1″ Intel Celeron Stainless Steel, Wide-Temp, 1000nit Panel PC
PCS6810APHEB- Intel® Celeron N2930 Quad-Core 1.83 GHz Processor, Windows® or Linux® Operating System, Fanless
- 4 GB RAM, 2 x GbE RJ45 Ethernet Ports, 2 x USB 3.0 Type A Ports, 2 x Serial Ports, 1 Audio Out, Optional Wi-Fi
- 304 Stainless Steel Front Bezel, IP66K/IP69K Rating, Extended Temperature (-20~60°C), NEMA 4 when panel mounted, EN-1672-2 Certified
- 1000 nit High Brightness, 10.1” Capacitive Touchscreen, 1280 x 800 Resolution
- VESA or Panel Mount
-
12.1″ Intel Celeron Stainless Steel, Wide-Temp, 1000nit Panel PC
PCS6812APHEB- Intel® Celeron N2930 Quad-Core 1.83 GHz Processor, Windows® or Linux® Operating System, Fanless
- 4 GB RAM, 2 x GbE RJ45 Ethernet Ports, 2 x USB 3.0 Type A Ports, 2 x Serial Ports, 1 Audio Out, Optional Wi-Fi
- 304 Stainless Steel Front Bezel, IP66K/IP69K Rating, Extended Temperature (-20~60°C), NEMA 4 when panel mounted, EN-1672-2 Certified
- 1000 nit High Brightness, 12.1” Capacitive Touchscreen, 800 x 600 Resolution
- VESA or Panel Mount
-
12.1″ Stainless Steel Industrial Touch Panel PC
PCS6812AP- Intel® Celeron N2930 Quad-Core 1.83 GHz Processor, Windows® or Linux® Operating System, Fanless
- 4 GB RAM, 2 x GbE RJ45 Ethernet Ports, 2 x USB 3.0 Type A Ports, 2 x Serial Ports, 1 Audio Out, Optional Wi-Fi
- 304 Stainless Steel Front Bezel, IP66K/IP69K, NEMA 4 when panel mounted, EN-1672-2 Certified
- Projected Capacitive 12.1″ Touchscreen, 800 x 600 Resolution
- VESA or Panel Mount
-
15.0″ C1D2, Stainless Steel, Wide-Temp, 1000nit Intel® Celeron® Industrial PC
AEx-815PH-- Intel Celeron N2930 Quad-core 1.83 GHz, Windows® 10 Operating System, Fanless
- 8 GB RAM, 1 x M12 8-pin for 2 x USB 2.0 type A, 2 x M12 8-pin for RJ-45, 1 x M12 3-pin for DC power, 1 x M12 12-pin for VGA, 1 M12 Serial Port
- 316 Stainless Steel Chassis, C1D2, C2D2, ATEX/ IECExx Zone 2/22, IP66, Extended Temperature -20~60°C
- 1000 nit High Brightness, 15″ Capacitive Touchscreen, 1024 x 768 Resolution, Optically Bonded
- VESA Mount
-
15.0″ Intel Celeron Stainless Steel Industrial Panel PC
PCS6815AP- Intel® Celeron N2930 Quad-Core 1.83 GHz Processor, Windows® or Linux® Operating System, Fanless
- 4 GB RAM, 2 x GbE RJ45 Ethernet Ports, 2 x USB 3.0 Type A Ports, 2 x Serial Ports, 1 Audio Out, Optional Wi-Fi
- 304 Stainless Steel Front Bezel, IP66K/IP69K, NEMA 4 when panel mounted, EN-1672-2 Certified
- Projected Capacitive 15″ Touchscreen, 1024 x 768 Resolution
- VESA or Panel Mount
-
15.0″ Intel Celeron Stainless Steel, Wide-Temp, 1000nit Panel PC
PCS6815APHEB- Intel® Celeron N2930 Quad-Core 1.83 GHz Processor, Windows® or Linux® Operating System, Fanless
- 4 GB RAM, 2 x GbE RJ45 Ethernet Ports, 2 x USB 3.0 Type A Ports, 2 x Serial Ports, 1 Audio Out, Optional Wi-Fi
- 304 Stainless Steel Front Bezel, IP66K/IP69K Rating, Extended Temperature (-20~60°C), NEMA 4 when panel mounted, EN-1672-2 Certified
- 1000 nit High Brightness, 15” Capacitive Touchscreen, 1024 x 768 Resolution
- VESA or Panel Mount
-
21.5″ Intel® Celeron® Stainless Steel Industrial Panel PC
PCS6821AP- Intel® Celeron N2930 Quad-Core 1.83 GHz Processor, Windows® or Linux® Operating System, Fanless
- 4 GB RAM, 2 x GbE RJ45 Ethernet Ports, 2 x USB 3.0 Type A Ports, 2 x Serial Ports, 1 Audio Out, Optional Wi-Fi
- 304 Stainless Steel Front Bezel, IP66K/IP69K, NEMA 4 when panel mounted, EN-1672-2 Certified
- Projected Capacitive 21.5″ Touchscreen, 1920 x 1080 Resolution
- VESA or Panel Mount
-
Extreme Environment Industrial PC, C1D2, Stainless Steel, Wide-Temp, Intel® Quad-Core
AEx-2410-- Intel Celeron N2930 Quad-Core 1.83GHz, Windows® 10 or Linux® OS options
- 8 GB RAM, 1 x M12 to 2x USB 2.0 Type A, 1 x M12 to leads (Power), 1 x M12 to VGA, 2 x M12 to RJ45 Ethernet, 1 x M12 to DE9 (Serial)
- Extended Operating Temperature (-20~60°C)
- VESA or Wall Mount
- Supports FactoryTalk® and other 3rd party SCADA software like SIMATIC WinCC, Ignition, and AVEVA Edge
- C1D2, C2D2, Class III, ATEx/IECEx Zone 2, Zone 22 Certified, 316 Stainless Steel Chassis IP66 all sides rating
-
Fanless Intel® Celeron® Quad-Core Compact Industrial PC
IPC2215A- Intel® Celeron® J6412 2.0GHz Quad-Core CPU, Windows® 10 or Windows® 11 OS options
- Up to 32 GB RAM, 2 x GbE Ports, 2 x USB 2.0 Type A, 4 x USB 3.2 Type A Ports, 4 x Serial Ports, 1 Audio Out, 2 x HDMI, Optional Wi-Fi/Bluetooth 5.2
- Operating Temperature (0°~60°C)
- Wall Mounting Kit included
- Supports FactoryTalk® and other 3rd party SCADA software like SIMATIC WinCC, Ignition, and AVEVA Edge
- Small Footprint
-
Intel® 12th Generation Hexa-Core Fanless Box PC
IPC2770A- Intel® 12th Generation Alder Lake Core™ i3-1215UE (Hexa-Core), Windows® 10, Windows® 11, or Linux® OS options
- Up to 64 GB RAM, 2 x GbE Ports, 2 x USB 2.0 Type A, 4 x USB 3.2 Type A, 2 x USB 3.2 Type C Ports (supports DisplayPort 1.2a), 1 Serial Port, 1 HDMI, 1 DisplayPort, 1 Audio Out, Optional Wi-Fi/Bluetooth 5.2
- Extended Operating Temperature (-20°~50°C)
- Wall Mount Kit included
- Supports FactoryTalk® and other 3rd party SCADA software like SIMATIC WinCC, Ignition, and AVEVA Edge
- Quad-Display UHD 4K Resolution Output
SCADA Software
AVEVA Edge, formerly known as Indusoft Web Studio, is a powerful HMI/SCADA software package for a wide range of industrial applications. With easy-to-use commands/tool bars and a Microsoft Windows™ environment, Aveva™Edge’s feature-rich application puts you in the driver’s seat of creating your industrial process.
Industries We Serve
Our products operate in some very tough environments and industries
If your goal is to enhance efficiency, optimize operations, avoid unplanned downtime, or lower total cost of ownership, we can help. Today’s technology offers innovative industrial process control solutions. Whether it’s integrating process control, motor control, safety, and information solutions, our products can help you address your unique challenges head on.
Learn more about the industries we serve and discover why more and more companies are choosing Maple Systems.
Customize Your HMI, HMI+PLC, or PC
Highlight your brand and differentiate your machine with a custom label
Company branding is a significant aspect of business marketing. By using custom labels on your products, you can create an identity to gain recognition from customers and potential buyers. It helps consumers recognize that the product was made by your company. Having this type of brand recognition can help your business stand out from competitors. Our Custom Labels:
- Fit Your Product Perfectly
- Offer Professional-Looking Packaging
- Strengthens Your Marketing Efforts
- Provides an Identity to Your Business
Manuals and documentation for products supported by Maple Systems Industrial Panel PC products.
- PC1000 Operations Manual
- PC2300 Operations Manual
- OMI6900 Operations Manual
- PCS6800 Operations Manual
- BPC2300 Operations Manual
- AEX Series Operations Manual
