MS1-L08G
- 8 x 10/100/1000 RJ45 ports
- Auto-Negotiation, Flow Control, Storm Control, 802.1Q VLAN, Advanced Management Functionality, Security, Traffic Control, RSTP, STP, Code Redundancy
- Industrial QoS (EIP (Ethernet/IP), PROFINET, and GOOSE packets)
- Redundant Power Supply
- Operating temperature -40℃~75℃ (-40°F~167°F)
- Metal Housing, Din-Rail
- IP30, UL, CE, FCC, RoHS, EMI, EMS, Shock, Vibration
- Supports MapleLink-Lite User Interface Dashboard
8 Port Lite-Managed Industrial Network Switch
MS1-L08G
$250.00
MS1-L08G is a lite-managed industrial switch designed for real-time monitoring and communication between controllers and devices in automation settings. This switch is used with industrial devices like PLCs, HMIs, and legacy devices. It offers auto-negotiation on all its ports and Modbus TCP to aggregate devices easily in industrial ethernet applications.
Our intuitive installation wizard lets you set up your switch in just three steps. The monitoring and management platform, Topology Map and Dashboard, give useful information in real-time to help users diagnose the network and troubleshoot without on-site technicians at all times.
Share the product:
Review this product
Share your thoughts with other customers about this product
Port Specifications
| SFP Ports | N/A |
| Fiber Port Connectors | N/A |
| Optimal Fiber Transceiver | N/A |
| Optimal Copper Transceiver | N/A |
| Wavelength (Bi-Directional) | N/A |
| Wavelength (Multi Mode) | N/A |
| Wavelength (Single Mode) | N/A |
| Fiber Nominal Max. Distance | N/A |
| RJ45 Copper Ports | Eight (8) |
| RJ45 Speed | 10/100/1000BASE-T |
| Auto Negotiation & MDI/MDI-X | Supported |
| RJ Nominal Max. Distance | 328 feet (100 meters) |
Performance
| Packet Buffer | 4.1Mbits |
| Jumbo Frame Size | 10k Bytes |
| MAC Table Size | 8K entries |
| L2 Forwarding Rate | 11.9Mpps |
| Switch Fabric | 16 Gbps |
| Throughput | 14,880 pps to 10 Mbps Ethernet ports 148,800 pps to 100 Mbps Fast Ethernet ports 1,488,000 pps to 1000 Mbps Gigabit Ethernet ports |
Reliability
| Code Redundancy | Dual Flash Memory |
| ERPS v1/v2 | <50ms revive time |
| RSTP | ~5-10 second revive time |
| STP | ~30-50 second revive time |
| Dual Homing | N/A |
| LACP | N/A |
| MSTP | N/A |
| Static Trunk | N/A |
Traffic Control
| Static Multicast Address | N/A |
| Flow Control | Per port (configurable) |
| Loop Detection | Per port (configurable) |
| Port Isolation | Per port (configurable) |
| Storm Alarm Threshold Per Port | Per port (configurable) |
| Storm Control | Per port (configurable) |
| Traffic Monitor | Abnormal Traffic Detection Per Port |
| VLAN Passthru | Supports up to 4094 VLAN IDs |
| LLDP Filter | Yes |
| Port Priority | Per port (configurable) |
| QoS Queue | N/A |
| 802.1p QoS/CoS | Port Based (configurable) |
VLAN
| 802.1Q VLAN | Yes |
| MAC-Based VLAN | N/A |
| Management VLAN | N/A |
| Port-Based VLAN | Port isolation (configurable) |
| QinQ | N/A |
IEEE Standards
| Compliance | 802.3, 802.3u, 802.3ab, 802.3x, 802.3az, 802.1AB, 802.1D, 802.1w, 802.1p, 802.1Q, 802.1X |
Power Details
| Input Voltage – Primary | 20~57 VDC |
| Input Voltage – Redundant | 20~57 VDC |
| Input Connector | Terminal Block |
| Max Input Current | 0.35A @ 24 VDC without alarm 1.35A @ 24 VDC with alarm |
| Max Power Consumption | 10W |
| Current Overload Protection | Yes |
| Redundant Power System | Yes |
| Reverse Polarity Protection | Yes |
Network Management Features
| GUI | Connect over HTTP or HTTPs |
| Auto Provision | N/A |
| Topology Map | LLDP Discovery, or Manual Registration for MapleLink/MapleLink-Lite |
| Device Management | Supports IP-Cam, HMI, PLC, Switch, IPC, and PC |
| TACACS+ | N/A |
| Installation Wizard | MapleLink-Lite |
| Dashboard | MapleLink-Lite |
| CLI | Connect over Telnet or SSH |
| SNMP v1/v2c/v3 | See Manual for supported MIBs |
| SNMP Trap | Yes |
| Management VLAN (MVLAN) | Yes |
| Firmware Upgradable | Remote or Onsite, Manual or Automatic |
| Configuration Backup/Restore | Text-Based File, Remote or Onsite, Manual or Automatic |
| Syslog | Yes |
| SNTP | Yes |
| LLDP | Yes |
| DHCP Client | Obtain an IP via DHCP |
| DHCP Relay | N/A |
| DHCP Option | N/A |
| Port Mirroring | Per port (configurable) |
| Server (Service) Control | See Manual for Supported Servers (Services) |
| Port Utilization | Yes |
| Alarm Information | Yes |
| Modbus TCP Client | Read only, See Manual for available function codes |
| Power Down Trap | Yes |
| Port Configuration | Enable/Disable, Speed/Duplex |
| ONVIF | Yes |
| Port Statistics | Yes |
| Remote System Reboot | GUI/CLI |
| User Account with Authority | Utilizing 802.1X |
Security Features
| STP/RSTP | Configurable BPDU Filter, BPDU Guard, ROOT Guard |
| GUI | HTTPs |
| CLI | SSH |
| IGMP Snooping | Yes |
| ACL (Access Control List) | Yes |
| Port Security | MAC Limit |
| Port-Based 802.1X | Utilizing RADIUS |
| Trusted Managed Host | Yes |
| DHCP Server Screening | N/A |
| DHCP Snooping | N/A |
| IP Source Guard | N/A |
| MAC Search | N/A |
| Managed Host | N/A |
| Refusal MAC | N/A |
| SNMPv3 | Yes |
| Static MAC | N/A |
| Sticky MAC | N/A |
Mechanical
| LED Panel | PWR, RPS, ALM, 1000, LNK/ACT |
| Dip Switches | Primary/Redundant Power Voltage Drop Alarm Setting |
| Alarm Relay | 1 Relay Output, 1A @ 24VDC |
| Enclosure Material | Black Powder-Coated Metal |
| Dimensions WxHxD | 50 x 116 x 100 mm (1.97 x 4.56 x 3.93 in) |
| Weight | 500g (1.10 lb) |
| Mounting | 35 mm DIN Rail |
Environmental
| Storage Temperature | -40°F~185°F (-40°C~85°C) |
| Operating Temperature | -40°F~167°F (-40°C~75°C) |
| Operating/Storage Relative Humidity | 5 to 95% RH (non-condensing) |
Certifications/Standards
| UL | cULus Listed |
| RoHS | Compliant |
| FCC | Class A Compliant |
| Ingress Protection | IP30 |
| Shock Test | IEC 60068-2-27 |
| Freefall Test | IEC 60068-2-31 |
| Vibration | IEC 60068-2-6 |
| EMI / CE | FCC Part 15 Class A, EN 55011 / BS EN 55011 Class A, EN 55032 / BS EN 55032 Class A, EN 61000-6-4 / BS EN 61000-6-4 |
| EMS / CE | IEC 61000-4-2 (ESD), IEC 61000-4-3 (RS), IEC 61000-4-4 (Burst), IEC 61000-4-5 (Surge), EN 61000-4-6 (CS), IEC 61000-4-8 (PFMF) EN 55035 / BS EN 55035 EN 61000-6-2 / BS EN 61000-6-2 |
| CE UKCA | Yes |
| CE | Yes |
Lite-Managed Switch Unboxing
We'll unbox one of our Lite Managed Industrial Network Switch units, review some of the many features, and a quick overview of our free UI
Simple and Intuitive User Interface with MapleLink
With straightforward configuration menus, both MapleLink and MapleLink Lite let you quickly set up your Lite or fully managed network switch. The integrated topology map of connected devices and neighboring switches gives you key information such as IP address and link status.
When you order the MS1-L08G the following items are included in the box:
1 x MS1-L08G
1 x Power Connector
1 x Quick Start Guide
