cMT3162XW
- Built-in Chromium Browser Version 132
- Capacitive Touchscreen Technology
- UL Listed, NEMA4 Rated
- IP66 Rated for Washdown Environments
- 1920 x 1080 Pixel Resolution
15.6" HTML5 Web HMI with Capacitive Touch
cMT3162XW
$1,200.00
Our cMT3162XW is equipped with a powerful quad-core CPU, 4GB Flash memory, and 1GB RAM, and a PCB coating, enabling it to handle complex tasks with ease. Designed for endurance, this 15.6″ Capacitive Touch Web HMI is NEMA4 certified and has an IP66 rating, providing exceptional dust and water resistance, making it suitable for the most demanding industrial environments.
Share the product:
Review this product
Share your thoughts with other customers about this product
System
| Memory (eMMC) | 4GB |
| CPU | Quad-Core RISC |
| Memory (RAM) | 1 GB |
I/O Ports
| Ethernet/LAN | LAN 1: 10/100/1000 Base-T x 1; LAN 2: 10/100 Base-T x 1 |
| CANbus | N/A |
| USB Host Ports | USB 2.0 x 1 (Type A) |
| USB Client Ports | N/A |
Display
| Resolution | 1920 x 1080 |
| Luminance (cd/m^2) | 300 |
| Colors | 16.2 M |
| Display Type | 15.6" WVA LCD |
| Size (W x H) | 13.60 x 7.68 inches [345.6 x 195 mm] |
Touch Screen
| Type | Tempered Glass, Projected Capacitive |
Electrical
| Input Power | 31.2 W |
| Power Isolation | Built-in |
| Input Voltage | 24 ± 20% VDC |
| Input Current | 1.3 A @ 24 VDC |
Mechanical
| Vibration Endurance | 10 to 25Hz (X, Y, Z direction 2G 30 minutes) |
| Enclosure Material | Front bezel: Plastic, Rear Enclosure: Aluminum |
| PCB Coating | Yes |
| Dimensions WxHxD | 15.75 x 10.35 x 1.03 inches [400 x 263 x 26.1 mm] |
| Panel Cutout (inches) [mm] | 15.12 x 9.72 [384 x 247] |
| Weight | Approx. 3.53 lbs. [1.6 kg] |
| Mounting | Panel mount, VESA 100 x 100 mm |
| Shock (Operation) | 25 g acceleration for 11 ms |
Environmental
| Storage Temperature | -4~140°F [-20~60°C] |
| Operating Temperature | 32~122°F [0~50°C] |
| Relative Humidity | 10% ~ 90% (non-condensing) |
Certification
| UL Type Rating | UL Type 4X (indoor use only) |
| NEMA Rating | NEMA 4 |
| IP Rating | IP66 Compliant Front Panel |
| CE | Yes |
| UL | cULus Listed |
| RoHS | Yes |
Customers who bought this product also bought:
-
Screen Protector, 15.6” (343mm x 193mm) 1 each.$35.00 -
Power Supply, Single Output, DIN Rail, 24VDC, 2.5A.$50.00 -
Input power connector$7.00 -
Mounting Clips Kit for cMT/HMI series (4 per set).$12.00 -
EasyAccess 2.0 Activation Card. Remote Access$99.00
- Chromium Based Browser Version 132
When you order the cMT3162XW the following items are included in the box:
- cMT3162XW Web HMI
- Quick Start Guide
- Warranty Statement
- 1 x Power Connector
- 12 x Mounting Clips
